1000VA off-Grid Inverter for Energy Storage System

Name: 1000VA off-Grid Inverter for Energy Storage System
Brand: all-electronics-online.com
SKU: 727457742
Availability: InStock
Rating: 4.7 (85 reviews)

Price:	Negotiable/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	GPDA1000VA-I
DC Rated Input Voltage:	48VDC
DC Input Current Rating:	30A
AC Rated Input Voltage:	220VAC
AC Input Rated Current:	5A
Rated Output Voltage:	220VAC
Rated Output Current:	4.6A
Nominal Capacity:	1000va
Machine Efficiency:	85%
AC Bypass Rated Output Voltage:	220VAC
AC Bypass Rated Output Current:	5A

Product Description

GPDA1000VA-I is one model from Goldpower Off-Grid inverter series, with AC bypass input and RS485 communication

Feature:

Flexible and efficient
Easy installation
Safe and reliable

Specification:

Model		GPDA1000VA-I
project			parameter
Input parameters	Dc input	DC working voltage range	40~60Vdc
		Rated input voltage	48Vdc
		input current rating	30A
	Ac input	AC voltage range	175~265Vac
		Rated input voltage	220Vac
		Input Rated current	5A
Output parameters	Inverter output	rated output voltage	220VAC
		Rated output current	4.6A
		output voltage accuracy	±5%
		Rated output frequency	49~51Hz
		Nominal capacity	1000VA
		machine efficiency	85%
		Output way	Two way communication output
	Ac bypass output	output voltage range	175~265Vac
		rated output voltage	220Vac
		Rated output current	5A
Protection		Input over-current protection	inlay
		Over temperature protection	inlay
		Meter protection	inlay
		Short circuit protection	inlay
		Output over-current protection	inlay
		Ac bypass input over-current protection	inlay
		Alarm function	inlay
Conventional parameters		Operating temperature	-20~55°C
		Relative humidity	5~95%
		Altitude	1500m
		Cooling method	Natural cold
		Noise	<50dB
		Dimensions	481.6×270×88(mm)
		Weight	5kg
		Certification	UL/TUV/CE

Shenzhen Gold Power Tech Co., Ltd. Was established in 1995, a leading excellence integrated power supply solutions partner in the industry. There's an independent industrial park with 80, 000 square meters in Pingshan district, Shenzhen, China. With more than 478 employees and many core intellectual property rights. The production capacity of all kinds of power supply is 6 million units every year, products are exported to more than 30 countries and regions over the world. Goldpower has been the national high-tech enterprise after more than 20 years of practice in power supply industry.

Our products cover Telecom, Green Solar Energy, Automobile application electronic and New energy fields formed six core product series, including standard telecom power supply, remote power supply, HVDC, Solar PV(photovoltaic), LED power supply and the car rechargeable power supply, widely used in communications, power electronics, automatic control, railway, military industry, medical treatment, financial self-service, LED, solar power and automobile charging control system.

We are ISO9001 approved enterprise and we can promise you good quality. Welcome to contact us for business cooperation.
