1kw DC AC Power Pure Sine Wave Inverter, Solar Inverter Pure Sine Wave off Grid with Battery Power

Prod Model:	TF20KW-50KW

Product Description

Foshan Tianfeng Energy Technology Co., Ltd. is a company specializing in the development, production and sales of solar power generation system products, wind power system products, solar and wind hybrid system (on-grid and off-grid systems).
For the solar system is mostly used for domestic power supply, the main charger, non-sun. Very useful system. Pure sine wave output, you can take all the inductive loads. Excellent sales in (France, the United States, Canada, Arabia, Pakistan, the United Arab Emirates, Bangladesh, Africa, Europe away from the local power grid, etc.) sales of popular products and new energy to lead the low carbon living.
Solar power grid system: Solar panels and inverter +
Off-grid solar system: solar panels + new inverter (controllers, inverters) + Battery
(The rest of the PV array combiner, racks, cable optional)
System Application:
Construction of the house and family of a residence;
2 residential construction, factories and warehouses
3 shopping malls, venues, stadiums and other
4 power plant, site operations and some huge projects.
Excellent quality, competitive price and better technical support and service, making the day the wind Energy Technology Co., Ltd in China, as the most valuable collaborator.

Our 30kw inverter competitive advantage:
1)Used copper transfromer;
2)LCD display
3)Bypass function
4)18 months warranty;
5)Ship the free parts for service.
6)CE certification


Technical specification

Model    TF300W    TF500W    TF700W
Capacity(W)    300W    500W    700
DC voltage(V)    12/24    12/24    12/24
Input voltage(V)    160-265VAC
Input frequency     45-65HZ
Output voltage    Four steps AVR, 110V/120V/220V/230V for optional
Output wave form    Pure sine wave
THD    ≤ 3%
Low-voltage protection(V)    9.8/19    9.8/19    9.8/19
Over voltage protection(V)    15/30    15/30    15/30
Recharge current    5-10A    5-10A    5-10A
Unit size(mm)    348*122*200    348*122*200    370*122*200
Transfer efficiency    87%--90%
Protections    Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection
Over load    120% of the rate capacity
Short circuit    300% of the rate capacity


Model    TF1K    TF1.5K    TF2K
Capacity(W)    1000    1500    2000
DC voltage(V)    24/48    24/48    24/48
Input voltage(V)    160-265VAC
Input frequency     45-65HZ
Output voltage    Four steps AVR, 110V/120V/220V/230V for optional
Output wave form    Pure sine wave
THD    ≤ 3%
Low-voltage protection(V)    19/39    19/39    19/39
Over voltage protection(V)    30/60    30/60    30/60
Recharge current    10-15A    10-15A    10-15A
Unit size(mm)    388*145*210    446*175*300    446*175*300
Transfer efficiency    87%--90%
Protections    Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection
Over load    120% of the rate capacity
Short circuit    300% of the rate capacity



Model    TF3K    TF4K    TF5K    TF6K
Capacity(W)    3000    4000    5000    6000
DC voltage(V)    48    48/96    48/96    48/96
Input voltage(V)    160-265VAC
Input frequency     45-65HZ
Output voltage    Four steps AVR, 110V/120V/220V/230V for optional
Output wave form    Pure sine wave
THD    ≤ 3%
Low-voltage protection(V)    39/78    39/78    39/78    39/78
Over voltage protection(V)    60/120    60/120    60/120    60/120
Recharge current    15-25A    15-25A    15-25A    20-30A
Unit size(mm)    473*220*386    473*230*490
Transfer efficiency    87%--90%
Protections    Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection
Over load    120% of the rate capacity
Short circuit    300% of the rate capacity


Model    TF10K    TF15K    TF20K    TF30K
Capacity(W)    10000    15000    20000    30000
DC voltage(V)    96    96/240    240/384    384
Input voltage(V)    160-265VAC
Input frequency     45-65HZ
Output voltage    Four steps AVR, 110V/120V/220V/230V for optional
Output wave form    Pure sine wave
THD    ≤ 3%
Low-voltage protection(V)    78    78/216    216/322    322
Over voltage protection(V)    120    120/272    272/480    480
Recharge current    20-30A    30-40A    without    without
Unit size(mm)    560*280*680    560*320*700    900*600*1380    900*600*1380
Transfer efficiency    87%--90%
Protections    Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection
Over load    120% of the rate capacity
Short circuit    300% of the rate capacity
