Product Description
Feature:
1.Combine with solar power controller and inverter hybrid function.
2.Completely controlled by CPU.
3.Inverter use copper transformer, pure sine wave output.
4..LCD displays, clearly to know the status.
5.have bypass function and AC charger (UPS function)
6.Perfect protection. Protect against anti-charge at night, battery over charger/over discharge, output short-circuit, against overload, against over-voltage, over-current protection ,etc.
7.Easy operation,only need connect the panels and batteries directly to the Hybrid solar inverter.Model SC1500W SC2000W SC3000W SC5000W
Rated power(W) 1500W 2000W 3000W 5000W
Rated DC voltage(V) 24Vor48V 48V or 96V
Line input Input voltage(V) 145-280V, 90-127V
Charge current(A) 7-25A
Inverter output Output voltage(V) 220VAC±5% &5V,12V DC
Output frequency 50Hz/60Hz±1%
Wave form Pure Sine Wave, THD<4%(Full Load)
Solar input Maximum voltage(V) 42V or 88V or 176V
Rated power(Wp) 1500Wp 2000Wp 3000Wp 5000Wp
Solar Controller Charge current(A) 50/30 40/30 60/40 80/60
MPPT range(V) 24v(20-34)48v(40-68),96v(80-136)
Charging efficiency 90%-95%, Peak on 97%
Other
Over charge protective voltage of battery(V) 24V(28.6),48V(57.2),96V(114)
Over charge recover-voltage of battery(V) 24V(27.4),48V(54.8),96V(109.6)
Voltage drop between solar
module and battery(V) ≤0.5V
Voltage drop between loads
and battery(V) ≤0.25V
Start speed of cooling fan Have
Environment Humidity 0-90% Maximum,non-condensable
Protective Functions Protection against anti-charge at night;Battery over charge/over discharge protection; Joint-reversed of solar modules
Control method MPPT
Size :D*W*H(mm) 465*220*480MM
N.W&G.W(kg) 26/32 32/38 40/49 44/52Model SC6000W SC7000W SC8000W SC10000W
Rated power(W) 6KW 7KW 8KW 10KW
Rated DC voltage(V) 96V or 120V
Line input Input voltage(V) 145-280V, 90-127V
Charge current(A) 28A-45A
Inverter output Output voltage(V) 220VAC±5% &5V,12V DC
Output frequency 50Hz/60Hz±1%
Wave form Pure Sine Wave, THD<4%(Full Load)
Solar input Maximum voltage(V) 176V or 220V
Rated power(Wp) 6KW 7KW 8KW 10KW
Solar Controller Charge current(A) 60A 80A 80A 100A
MPPT range(V) 96v(80-136);120V(100-170V)
Charging efficiency 90%-95%, Peak on 97%
Other
Over charge protective voltage of battery(V) 96V(114);120V(142V)
Over charge recover-voltage of battery(V) 96V(109.6);120V(137V)
Voltage drop between solar
module and battery(V) ≤0.5V
Voltage drop between loads
and battery(V) ≤0.25V
Start speed of cooling fan Have
Environment Humidity 0-90% Maximum,non-condensable
Protective Functions Protection against anti-charge at night;Battery over charge/over discharge protection; Joint-reversed of solar modules
Control method SPWM
Size :D*W*H(mm) 535*280*680MM
N.W&G.W(kg) 64/72 68/76 70/83 73/88
FAQQ: What can be included for this system from TANFON?A:This system includes:solar panels, PV array combiner,Solar inverter with MPPT solar controller build in,lead-acid AGM free mainentance battery,solar panel rack,cables.,etc. Q:What's the advantage for this solar system from TANFONA:1.
installation support.2.The most advantage:On grid energy backup(not means sell electricity,just backup) 3.CE Rohs Certified
4.100% high quality materials
5.have Open factory in local.--Best after sales service ! Q: Is the system solution always the same? Can I customize one?A: Yes we have our professional teams making solutions for our clients. Solutions are mainly customized based on different sunshine time and power consumption. So the 1kw system may be with different configuration. Q: Is the solution for complete set? If not, what else are needed?A: Yes we can provide solution of complete set. If you don't need complete set, basic parts are also available. Q: Who arranges the shipping?A: We could help you arrange the shipment, we have good service forwarder in Guangzhou. Q: What's the difference between off grid and on grid solar power system?A: Off grid solar power system doesn't connect to the power grid. In general, it includes solar panels, charger controller, batteries and inverter. This system will store the solar power into the batteries, batteries energy will be converted the electricity power to supply the appliances working through the inverter.On grid solar power system connects to the power grid. In general, it includes solar panels, grid-connected inverter, the solar power will be converted the electricity power to appliance working directly. When the solar power is off, the power grid will replenish the electricity power to appliances working. Q: Can the inverter switch automatically to national grid to protect batteries.A: Yes. It can also connect to third generator like diesel generator. Please tell our sales before production. Q: What is the lifetime of the solar power system?A: Solar panels' lifetime are 25 years, charger controllers 5~ 7 years, inverters 5~7 years, batteries 6~8 years. Q:what is TANFON solar system after sales service?A: during the warranty ,Solar panel--ship free new one ;battery-ship the new one ,Inverter/controller---ship free PCB by DHL or Fedex. Q:how about TANFON solar system quality?A: we promise our quality materials ,and after sales service ,also have many project in all over the world ,contact our sales get the project picture Q:what is your trade AsusuranceA:100% product quality protection 100% product on time shipment protection 100% payment protection for your covered amount If you have more question, welcome to contact us freely, Choose TANFON, Choose Satisfaction! project picture:
