1X8 Fiber Optical PLC Splitter with ABS Box
| Price: |
US $ 10-25/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal,Money Gram |
| Prod Model: |
FA-PLCA1×8SP |
| Connector Type: |
Sc,LC,St,FC, Customized or Without Connector |
| Input/Output Length: |
Customized |
| Input/Output Diameter: |
0.9mm, 2.0mm, 3.0mm |
| Jacket Color: |
Default or Customized Based on MOQ |
| Jacket Material: |
PVC or LSZH |
| Fiber Type: |
G.657A1 or Customized |
| Wavelength: |
1260~1650 Nm |
| Optical Ratio: |
Average |
| OEM: |
Available |
| Wiring Devices: |
Integrated Wiring |
| Certification: |
GS |
| Condition: |
New |
Product Description
FA-PLCA1×8SP, Fiber Optical PLC Splitter, with ABS box, 1×8, With SC/PC ConnectorProduct Introduction:Fiberall Fiber Optical PLC(Planar Lightwave Circuit) Splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (OLT) to multiple premise locations (ONU). It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting as a low-cost solutions. Fiberall has ability to provide all arrange of 1xN and 2xN PLC splitters that are tailored for specific applications. Applications:1.CATV/CCTV Links 2.FTTX Systems (FTTB, FTTC, FTTD, FTTH, FTTO, FTTP, FTTZ etc)3.PON Networks (EPON, BPON, GPON)4.Access/Metro Networks5.Optical Signal Distribution6.Long Haul TelecommunicationPerformance Features:1.Low insertion loss2.Low PDL (Polarization Dependent Loss)3.High Polarization Extinction4.Excellent channel-to-channel uniformity5.Compact size 6.Wide operating wavelength: 1260nm~1650nm7.Wide operating temperature: from -40°C to 85°C8.High reliability and stability (-40°C~85°C)9.Bend sensitive G657A fiber Standard Compliance:Telcordia GR-1209-CORE-2001Telcordia GR-1221-CORE-1999RoHSYD/T 2000.1-2009 (China National) Technical Specifications:| Parameter | Unit | 1x8 |
| Premium Grade |
| Insertion Loss | Max. | dB | 10.5 |
| Channel Uniformity | Max. | dB | 0.8 |
| Polarization Dependent Loss (PDL) | Max. | dB | 0.2 |
| Operating Wavelength | 1260~1650 nm |
| Return Loss | UPC/APC | Min. | dB | 50/55 |
| Directivity | Min. | dB | 55 |
| Operating Temperature | ºC | -40~85 |
| Storage Temperature | ºC | -40~85 |
| Connector Type | / | SC, LC, ST, FC etc. |
| Fiber Type | / | Complied to G.657A1 or Customized |
Order Information:| Items | Options |
| Channel | 1X2, 1X4, 1X8, 1X16, 1X32, 1X64, 2X2, 2X4, 2X8, 2X16, 2X32, 2X64 |
| Encapsulation Type | Round steel tube, Mini rectangle steel package, ABS box, Card type (LGX box), Rack mounted |
| Wavelength | 1260-1650nm |
| Optical ratio | Average |
| Input/Output diameter | Ribbon fiber, 0.9mm, 2.0mm, 3.0mm |
| Jacket of Input/Output Cable | PVC or LSZH |
| Connector type | SC, LC, FC, ST, MU, DIN, E2000 and so on or without connector |
| End Polishing | PC, UPC(SPC) or APC |
| Cable length | Customized |
| Fiber Type | SM G652D or G657 |
| Test report | YES |
| RoHS | YES |
Available Customized Options: 1, Customized print on cable ( 2.0mm or 3.0mm)2, Customized packing3, Customized labelMany others...
Shenzhen Fiberall Technology Co., Ltd was started in 2007 and we are located in Shenzhen China. As a company engaged in fiber optical engineering related products, our main business including: Research and development (R&D), manufacturing, marketing; Optical engineering solution design; Maintenance, consulting service and accessories outsourcing.
Our main products are: All kinds of Fiber PLC Splitters, FBT Couplers, Fiber Cable Assemblies, Patch Cords, Fiber Pigtails, Fiber Adapters, Patch Panels, Fiber Optical Transceivers, OLT (Optical Line Terminal), OUN (Optical Network Unit), FTTX, Equipments & Accessories for Fiber Test, Installation, Maintenance & Repair.
With eight years' experience in fiber optic, Fiberall established a relatively perfect products and service system, with rich industry experience, comprehensive technology and high-quality team, we are able to provide our customers with OEM & ODM service, project implementation, maintenance, and after-sale service and we have ability to meet different requirement from different customers like distributors, operators, contractors and users etc.
