2.4G 4 Zone Wireless/RF Touch Button LED RGB Controller

Name: 2.4G 4 Zone Wireless/RF Touch Button LED RGB Controller
Brand: all-electronics-online.com
SKU: 825196725
Availability: InStock
Rating: 4.4 (46 reviews)

Price:	US $ 10/Piece
Min Order:	10/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	SU-TOUCH-RGB1
Working Temperature:	-20-55
Output:	3 Channels
Current:	4A Each Channel
Connection Mode:	Common Anode
Controller Size:	L85×w45×h23mm
Remote Size:	L150×w40×h13mm
Warranty:	2 Years
Lifespan:	50, 000h
Control Way:	Touch Remote Wireless
Application:	LED Products
Signal Transmission:	RF Remote Control
Type:	Button
Certification:	CE
Universal:	Universal
Transmission Distance:	<50m
Material:	Plastic
Battery Type:	AAA Battery
Voltage:	DC12-24V

Product Description

Product Description
This 4 zone 2.4G RF RGB Controller is the touch button RF wireless remote controller, the most advanced PWM (pulse width modulation) control technology have been adopted. It can be installed & used easily, plenty modes can be selected, speed & brightness can be adjusted with the remote. It also has memory function because we inside the memory chip on the PCB. With all these high functions, we still make it so tiny, and make it more economical and practical. It's mainly used to control all kinds of constant voltage led lights, such as: LED source, LED strips, led wall washer, wall Glass curtain lights, etc.

Direction for use
Function introduction:
1,Use the 2.4G frequency RF remote control, no need to make the remote direct to the controller,and the RF remote can controlled it across obstacles.
2,In the open area remote control distance is about 30 meters.
3,Adopt the press key and touch wheel control remote, slightly touch the color wheel can adjust the light's brightness smoothly .

Operation method:

1.Connect the load wire at first, following by the power wire; Please ensure short circuit can not occur between connecting wire before you turn on the power;
2.Only the power button is effective in the OFF station, press the power button for the first time then controller will enter to the last mode before turn of the controller last time (memory off function).
3. Mode+/- can select the 8 modes as below:

No	Mode
1	7 color fade
2	White fade in and out
3	Red fade in and out + Green fade in and out + Blue fade in and out + white fade in and out
4	7 color jump
5	Red fade in and out+ jump flash 3 times
6	Green fade in and out+ jump flash 3 times
7	Blue fade in and out+ jump flash 3 times
8	Auto Cycle
