210W 30~58V 3.8A Fanless Lithium Battery Charger

Name: 210W 30~58V 3.8A Fanless Lithium Battery Charger
Brand: all-electronics-online.com
SKU: 817990525
Availability: InStock
Rating: 4.5 (113 reviews)

Price:	US $ 15.5-16.5/Piece
Min Order:	500/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	PLD210-EVCS09-58
Output Power:	210W
Color:	Black
Warranty:	2 Year
Type:	Lithium Ion Battery Charger
Charging Type:	Electric Charger
Principle:	PWM

Product Description

210W 30~58V 3.8A Fanless Lithium Battery Charger

Powerland's 48V Lithium battery chargers are designed with ultra-high efficiency, as well as full metal case enclosure. The extraordinary performances of low power dissipation and water proof provide the chargers high reliability and super long life time. This series of chargers offer solid power conversions for applications such as e-vehicles, e-bikes, e-motorcycles, e-boat, e-machines, etc.

Features
Universal AC Input :185~265 Vac
Output Power:210W
High ReliabilityEfficiency Up to 93%
All-around Protections:OVP,OCP,SCP,OTP,UVLO
Low Temperature Start Up -20 ºC
High Temperature Full Load Operation:50 ºC
IP65 Ingress Grade
Three Times Life Time
2 Year Warranty

Model Specifications

Model Number	Output Power	Output Current	Output Current Range	Output Voltage Range
PLD210-EVCS09-58	210W	3.8A	95%Io~105%Io	30V~58V

Specifications

Model	PLD210-EVCS09-58
Output Voltage	30V~58V
Output Current	3.8A
Max. Output Voltage	58V
Output Voltage @ Open Circuit	58V
Current Accuracy	±5%
Voltage Accuracy	±0.5%
Output Power	210W
Input Voltage Range	185~265Vac
Input Frequency Range	47-63Hz
Input Current(MAX)	3A@230Vac
Max. Input Power	235W
Efficiency	93% @ 230Vac
Protections	OVP, OTP , SCP, Open Circuit Protection
Environmental Protection Rating	IP65
Working Temp	-20ºC~+50ºC
Cooling	Free Air Cooling
Max Case Temp. (o C)	<55ºC @ 25ºC
Surge Protection	1kV/2kV
Isolation Test	Primary to Secondary: 3000Vac / 10mAMax / 60seconds Primary to Earth: 1500Vac 10mA max./60 seconds Secondary to Earth: 500Vac 10mA max./60 seconds
Dimension	161X84X48mm (LxWxH)
Weight	1.32Kg
Life Time	30,000 hours at 25ºC, 230Vac Input, and Continuous Full Load Output

FSP-Powerland Technology Inc. is a leading customized power company, providing full service and solutions for industial, military, medical and consumer applications. Since established in spring 2009, Powerland has attracted international expertise into its R&D team. Powerland never stops integrating technology innovation with experienced product development, to design and manufacture high-end power electronics products featured with high efficiency, high reliability, super long life, and high power density.

Since its establishment, Powerland has been focusing on green power products, including LED lighting power, solar power, MID/large-scale battery power, and other high-efficiency power supplies. In addition, to strengthen our technology and market competitiveness, Powerland has established strategic cooperation relationships with multiple global companies, and carries on the customized design service for challenging power solutions.

Looking into the future, Powerland will continue our "Me-First" product strategy, and will extend our advantages in leading-edge technologies. Together with the solid base of FSP-Group, and our sharp market insights and outstanding manufacturing quality, Powerland looks into "breaking limits, establishing the horizon" in green energy and power electronics field
