| Prod Model: |
JL4562 |
| In Put Voltage: |
90 ~ 264vact127 ~ 370VDC |
| Output Voltage: |
5/12/15/24/36V |
| Power: |
35W |
| Warranty: |
2 Years |
| Item Name: |
Switching Power Supply |
| Usage: |
Light |
| Output Type: |
Single |
| Driving Method: |
LED Regulator Voltage |
| Circuit Structure: |
PWM Controlled |
| Brand: |
Meanwell |
Product Description
Why choose us
feature
Withstand 300VAC Surge input for 5 seconds
Universal AC input I Full range
Cooling by free air convection
Protections: Short circuit I Over load I Over voltage
Fully isolated plastic case
100% full load burn-in test
Small and compact size
Class 2 power unit
IP 42 design
Pass LPS
Specification
| MODEL | APV-35-5 | APV-35-12 | APV-35-15 | APV-35-24 | APV-35-36 |
| | DC VOLTAGE | 5V | 12V | 15V | 24V | 36V |
| | RATED CURRENT | 5A | 3A | 2.4A | 1.5A | 1A |
| | CURRENT RANGE | 0 ~ 5A | 0 ~ 3A | 0 ~ 2.4A | 0 ~ 1.5A | 0 ~ 1A |
| OUTPUT | RATED POWER | 25W | 36W | 36W | 36W | 36W |
| | RIPPLE & NOISE (max.) Note.2 | 120mVp-p | 150mVp-p | 150mVp-p | 180mVp-p | 180mVp-p |
| | VOLTAGE TOLERANCE Note.3 | ±5.0% |
| | SETUP, RISE TIME Note.6 | 1500ms, 40ms / 230VAC 1500ms,40ms / 115VAC at full load |
| | HOLD UP TIME (Typ.) | 20ms/230VAC 12ms/115VAC at full load |
| | VOLTAGE RANGE Note.4 | 90 ~ 264VAC 127 ~ 370VDC |
| | EFFICIENCY (Typ.) | 76.5% | 83% | 84% | 84% | 85% |
| INPUT | AC CURRENT | 0.5A/230VAC 0.75A/115VAC |
| | INRUSH CURRENT(Typ.) | COLD START 45A(twidth=440μs measured at 50% Ipeak) at 230VAC |
| | MAX. No. of PSUs on 16A CIRCUIT BREAKER | 6 units (circuit breaker of type B) / 10 units (circuit breaker of type C) at 230VAC |
| | LEAKAGE CURRENT | 0.25mA / 240VAC |
Packaging&transportation:
FAQ:
Q:How will I know whether to use a Constant Voltage or Constant Current driver with my LED's?
A:Usually the manufacturer of the LED load will specify whether the LED module is for use with either a Constant Voltage or Constant Current driver.
Q:What is input voltage range of LED Driver?
A:85-264VAC,120-373VDC
Q:What is output DC voltage of LED Driver?
A:3.3/5/12/15/24/36/48V
Q:What is the working temperature?
A:-30~+70ºC
Q:What is the warranty for an LED Driver?
A:Our LED drivers have a 5 year limited warranty
