230/400V 1 2 3 4 Pole 2 AMP IEC 60898 ETI Etn Mini Circuit Breaker

Name: 230/400V 1 2 3 4 Pole 2 AMP IEC 60898 ETI Etn Mini Circuit Breaker
Brand: all-electronics-online.com
SKU: 837044115
Availability: InStock
Rating: 4.7 (110 reviews)

Price:	US $ 3.2-3.21/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Rated Current:	1A-63A
Rated Voltage:	230/400
Color:	White and Green
Rated Frequency:	50/60 Hz
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Electric Type
Speed:	Normal Type Circuit Breaker
Installation:	Insert
Structure:	MCB
Poles Number:	3
Certification:	CE

Product Description

Model	FG65-63	NPB1-32	NPG1-125
Standards	IEC/EN 60898-1	IEC/EN 60898-1	IEC/EN 60947-3
Rated Current(A)	1,2,3,4,6,10,16,20,25,32,40,50,63	1,2,3,4,6,10,16,20,25,32,40	32,63,100,125
No.of Pole	1P,2P,3P,4P	2P	1P,2P,3P,4P
Rated Voltage(V)	230/400	230/400	230/400-240/415
Frequency(Hz)	50	50/60	50/60
Breaking Capacity(kA)	6	4.5	N/A
Rated impulse withstand Voltage(V)	4000	4000	4000
Electrical life(Circle)	4000	4000	1500
Mechanical life(Circle)	10000	20000	8500
Characteristic	B,C,D	B,C,D	N/A
Mounting	DIN rail EN 60715	DIN rail EN 60715	DIN rail EN 60715
Connection	Cable	Cable	Cable
Auxiliary Contact	Optional	Optional	Optional
Shunt Release	Optional	Optional	Optional
Under Voltage Release	Optional	Optional	Optional
Alarm Contact	Optional	Optional	Optional
Protection	Short Circuit & Overload	Short Circuit & Overload	Disconect

Our company supplys different kinds of products. High quality and favaroble price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price. If you are interested in any of our products, or wish to place a customized order, please contact us. We will do our best to meet your needs.

Yueqing Lovadon Electric Co., Ltd wsa founded in 2012, located in Liushi Chandong Industrial Zone where is near the national scenery area-Yandang Mountain. Our company covers an area of 500m² And has around 30 staff members. It has advanced automation equipment and testing equipment, with a number of high-education management team and staffs. The company speciallized in manufacturing low voltage and high voltage electrical product such as Circuit Breaker, Contactors, Distrubition Boxes, Automation products, Switches, Power source, Lightning arrester, Composite suspension insulator, and so on. Guaranteeing stable and timely supply, credible quality and sincere service, our products sell well in both domestic and overseas markets.
