40W Round Not Dimmable LED Driver for LED Light

Name: 40W Round Not Dimmable LED Driver for LED Light
Brand: all-electronics-online.com
SKU: 766372165
Availability: InStock
Rating: 4.5 (36 reviews)

Price:	US $ 4.05-5.65/Piece
Trade Terms:	FOB
Min Order:	50/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	T40M
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimension:	D100*30 (mm)
IP Degree:	IP20
Dimmable:	No
Protection:	Short Circuit
Workspace:	40W
Usage:	Light
Output Type:	Single
Driving Method:	LED Constant Current
Circuit Structure:	Triac
Power Supply Mode:	Customed
Modulation System:	Triac
Brand:	No Brand

Product Description

40W Round not dimmable led driver for led light

Features:constant current

Model No.	DR-CC-40
Input Voltage Range	100-240V/AC
AC Frequency	48-62Hz
output mode	constant current
output current	500/700/900 ma
on load voltage	65/50/40
output power	40w max
power factory	>0.95
efficiency	80-86%
dimension	D100*30 (mm)

Specifications:

Environmental Specifications
Operating Temperature	-25~+55°C
Storage Temperature	-40~+70°C
Thermal Dissipation	Nature
Relative Humidity	5-95%
Isolation Voltage	In/Out 3000VAC
Vibration	5-55Hz/2g,30 Mimutes
Life time	50000Hours,at TC max

Pictures:

Conformity & Standards:
EN 55015
EN 61000-3-2-CLASSIC
EN 61000-3-3
EN 61000-4-2,3,4,5,6,8,11
EN 60598

Quality guarantee:

All the driver have automatic protection of overload, short circuit, temperature,etc.

Guarantee:1.The warranty period is 2 years.

2.During the time ,if the product have any question ,we can change the same to you.

We can design the product according to your requirement.

Packing:

Bubble bag ,inner box,and carton etc
