40watt Laser Power Supply for DIY Laser Cutting Machine

Name: 40watt Laser Power Supply for DIY Laser Cutting Machine
Brand: all-electronics-online.com
SKU: 789231235
Availability: InStock
Rating: 4.7 (29 reviews)

Price:	US $ 40/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	OD-DY40
Output Type:	Single
Warranty:	1 Year
Output Power:	1 - 50W
Input Voltage:	220V
Connection Mode:	Series Switching Power Supply
Starting Mode:	Self-excited Switching Power Supply
Voltage Regulating Mode:	Frequency Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	CE
Brand:	Od

Product Description

40Watt Laser Power Supply for DIY Laser Cutting Kits

40W Co2 Low Power Supply special designed for 30W - 50W CO2 laser tube and mini laser engraver,laser stamp engraving machine, very small volume and weight, very long warranty and lifetime.

1. Main Feature :

1) Good compatibility: It can be applicable to 30W, 40W, 50W laser tube.

2) Fast response speed and effect.

3) Dramatically lengthen the life of laser.

4) Easy Control: The start and stop of laser can be easily controlled by TTL level. And there are protection switch to test the external water, ventilation, etc.

5) Easy control of laser power: Both 0-5V analog signal and PWM signal can control the laser power.

6) The power supply has open circuit protection: Under the condition of good protective earth, the power supply can work in open-circuit for a short time, which could avoid the damage of laser power supply because of the bursting of laser tube, thereby enhancing the life of power supply.

7) The power supply can take feedback interface which can be used in closed-loop control and testing the working current of laser.

8) The power supply adds a new function, that is timely scene judging which part is damaged, laser tube or laser power.

9) Application: Acrylic sculpture, cut; Fabric sculpture, cut; Rubber sheet sculpture, cut, etc.

2. Specification :

Model Parameters		40W Laser power supply
Input	Input Voltage	AC220V+/-10% (Need AC110V products, ordering need indicate)
	AC frequency	47 - 440HZ
	Max. Input power	350W
	Max. Input current	3A
Output	Maximum output voltage	DC25KV
	Maximum output current	DC20mA(depending on the laser tubes of different manufacturers)
Efficiency		>/=90%(Full load)
MTBF		>/=10000 Hours
Response speed		≤ 1ms (Time from the TTL Signal is given to the output current up to 90% pre-setting current)
Withstand Voltage		Input-Output, Input-Enclosure: AC1500V 10mA 60S, Output cathode is connected with enclosure.
Environment		Operating temperature: (-10-40)degree Celsius,Relative humidity: ≤90%
Cooling		Force-Air Cooling (FAC)
EnvironmentalRequested	Working temperature	-10 - 50 degrees centigrade
	Storage of temperature	-20 - 75 degree centigrade
	Relative Humidity	Maximum 85% RH (non-condensing)
	Altitude	100,000 feet of work 200,000 feet of storage, does not work
Cooling methods		Forced air cooling (fan cooling)
Dimensions (LWH)		L×W×H=201813(cm)
Weight		2.0KG
