6kw Three Phase Inverter/6kw Power Inverter
| Price: |
Negotiable/Piece |
| Trade Terms: |
CIF |
| Min Order: |
1/Piece |
| Pay Type: |
T/T |
| Prod Model: |
TF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity: |
T6kw |
| Materials: |
Copper Transformer |
| Make Way: |
Three PCB Box |
| Inptut Voltage AC: |
380V |
| Input Battery Voltagte DC: |
96V |
| Output Voltage: |
380V |
| Size: |
523*260*750mm |
| Warranty: |
18 Months |
| Serive: |
Ship The Free Parts |
| OEM: |
Yes |
Product Description
Our 6kw three phase invertercompetitive advantage:
1)Used copper transfromer;
2)LCD display
3)Bypass function and with AC charger;
4)18 months warranty;
5)Ship the free parts for service.
6)Working for single phase and three phase
We promise our best quality and after sales service. Make TANFON as your most valuable cooperator in China.
| MODEL | T1K | T3K | T5K | T10K | T15K | T20K | T30K | T60K | T100K |
| Power | 1KW | 3KW | 5KW | 10KW | 15KW | 20KW | 30KW | 60KW | 100KW |
| Power Factor | 0.8 |
| Input | Phase | 3 phase 4 wire and ground |
| Voltage Range | 380V± 20%(3 phase), phase voltage 220V |
| Frequency Range | 45 - 65Hz |
| Rectifier | 3 phase 6 pulses, 12 pulses is optional |
| Output | Phase | 3 phase 4 wire and ground |
| Wave form | Pure sine wave |
| Crest Factor | 3: 01 |
| Rated voltage | 380/400/415V optional
+ -1% for static load, 5% for fluctuant load |
| Phase voltage setting | 200 - 244VAC, pls confirm when order |
| Transient response | +/-5%, 10ms |
| Frequency | 50 / 60 Hz + / - 0.05% |
| Total-harmonic distortion | < 3% linear load, < 5%( nonlinear load) |
| Short circuit current | Short current for 0.1s (200% current) |
| Overload capacity | Overload 125% for 10 Ms, 125%-150% for 1min. automatically resume when load become normal |
| Battery | Battery | Maintenance free lead-acid cell |
| DC Voltage | 48v or 96V(1-15KW) | 384V |
| Max Charge Current | 6-30A adjustable |
| Bypass | Type | Static state + manual maintenance bypass |
| Input Phase | 3 phase 4 wire and ground |
| Input voltage range | 15% - 25% (the front control panel selectable) |
| Transfer time | Inverter / bypass transfer switch time(Overload): 0ms inverter / bypass transfer switch time (fault inverter) 1ms |
Efficiency
| Whole unit | > 85% |
| Inverter | 91 | 91 | 92 | 92 | 93 | 93 | 95 | 95 | 95 |
| Remote signaling | Dry contact (battery low, battery discharging, bypass/ fault); output 12Vdc/80mA, Optional parts |
| Communication interface | RS232 ( SNMP, modem optional ) |
| Running temperature | 0-40 degree Celsius |
| Relative Humidity | Less than 95% (without condensing) |
| Noise at 1 M | less than 60 dB |
| Degree of protection | IP20 |
| Applicable Standards | EN50091-1-EMC EN50091-2liv. A |
| Product size(mm) | 560*230*570 | 590*470*730 | 900*600*1380 | 1200*900*1820 |
| product weight(Kg) | 30 | 40 | 54 | 104 | 125 | 190 | 380 | 690 | 800 |
| Package size(mm) | 640*300*730 | 690*570*850 | 1135*810*1430 | 1450*1110*1880 |
| Package weight(Kg) | 32 | 50 | 60 | 123 | 145 | 215 | 420 | 750 | 860 |
Who we are?
Foshan Tanfon Energy Technology Co., Ltd is a professional manufacturer of green energy products with great commitment, contribution heart and responsibility.
What we do?
We are specialized in the R&D, manufacture and sale of the high quality environmental solar system, wind energy turbine, solar street light, solar pump and pure sine wave inverter, etc.
Now we are having the main series products as below:
1. Solar inverter
2. Solar controller(PWM and MPPT)
3. Portable solar system
4. Solar power system
5. Solar on grid system
6. Solar refrigerator system
7. Wind power system
8. Wind &solar hybrid system
9. Solar street light system
10. Solar air conditioner system
With these items as our weapons, we can fully supply the solutions for our clients' different needs.
We adhere to "quality first, users first" purpose, devoting ourselves everyday into setting up a suitable system for all of our clients.
How we do?
For the production, we have the professional production lines(Automatic series welding machine, EL test machine, Automatic frame machine, Special debug machine). Each step of production is under strict quality control. Our products are qualified with CE, RoHS, ISO certification.
For the service, we promise the quality. All products have the certain warranty and the new part would be shipped freely on time for service during the warranty. Also our company has started opening the factories in some countries, so it is very convenient to service you well at local.
Importantly, with a professional installation team, we have been to many countries(like Egypt, Bangladesh, Chad, Nigeria, Ghana, Doha, Pakistan) for installation service as well as win good feedback from the customers.
Specializing in installing projects from design, detailing, fabrication to erection, having continue cooperation with engineers, exclusive agents and the foreign business partners, we are now sincerely hoping to join hands with you to create a better future together at the principle of win-win cooperation.
Our Vision:
Tanfon create a solar kingdom for you
Our Mission:
Sincere, All-win, Unite, Aggressive.
Our Core Value:
100% Commitment 100% Contribution
100% Possibility 100% Time
