C 1K (S) -Rtx 110V/220V High Frequency Online UPS with Transformer

Name: C 1K (S) -Rtx 110V/220V High Frequency Online UPS with Transformer
Brand: all-electronics-online.com
SKU: 839328225
Availability: InStock
Rating: 4.9 (30 reviews)

Price:	US $ 109.8/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	C 1K(S)-RTX
Product Name:	C 1K(S)-Rtx 110V/220V High Frequency Online UPS
Phase:	Single Phase
Type:	On-line
Protection:	Short Circuit
Classification:	Power
Brand:	Greenmaster

Product Description

C1K(S)-RTX 110V/220V High Frequency Online UPS with Transformer

Key Features

1.Double input or output 110V/220V High frequency online UPS

2.1KVA/2kVA/3KVA, 0.9PF

3.Single input 220V or double input 110/220V

4.Double output 110V and 220V or single ouput 220V

5.Fully digitized microprocessor control

6.Wide input voltage range

7.Advanced PFC technology

8.Self-testing when UPS startup

9.Advanced battery management

10.Automatic battery charging in UPS off mode

11.Lightning and surge protection

12.Short circuit and overload protection

13.Smart RS232 communication with monitoring software

14.LED or LCD display

15.LCD Disply ,SNMP,EPO, USB Communication is option

Technical Specifications

Item	Model	C1K-RTX	C1KS-RTX
Capacity	VA / Watts	1kVA/0.9KW	1KVA / 0.8KW
Input	Normal voltage	L+N=220V or L+N=110V / L+N=220V
	220V Voltage range	a) (110±5 ~ 300±5) VAC when Load at 0-60%
		b) (120±5 ~ 300±5) VAC when Load at 60-70%
		C) (140±5 ~ 300±5) VAC when Load at 70-80%,
		D) (160±5 ~ 300±5) VAC when Load at 80-100%
	110V Voltage range	80-150VAC
	Power Factor	0.97
	Frequency range	Normal 50HZ/60HZ±4, 40~60Hz(set by winpower)
Output	Voltage range	110V/220VAC or 220V +-1%,
	Frequency range	50Hz/60Hz+-0.2 (Battery mode)
	Wave form	Pure Sine Wave
	Transfer time	0 ms (AC mode and battery mode)
		Transfer time: 4ms (typical 2.5ms),AC mode and bypass mode
	Distortion (Full Load) linear load	≤3%	≤3%
	Degree of distortion (Full Load) nonlinear load	≤6%	≤6%
	Overload capacity	>108% 30s turn to bypass mode; >150%, 300ms turn to bypass
	Load peak ratio	3:1(max)
Battery	Type	Maintenance free valve regulated lead acid (VRLA) battery
	Battery voltage	36VDC	36VDC
	Battery number	External 312V7.2AH	External
	Backup time (Full load)	>5Mins	up on battery
	Backup time (Half load)	14Mins	up on battery
	Recharge time	90%capacity after 5 hrs charging	up on battery
Bypass		Automatic while overload or ups fail.
	Before ON	Default ON. Workable set by Winpower
	Voltage Range	Default 80-260V, workable set by WinPower to 80-286V
Display	LED	Load level / Battery level / Battery mode / Line mode / Inverter , Bypass ,Over load , Fault
	LCD, Option	IP/OP VAC HZ, BAT % , LOAD % , LINE / BAT MODE
Audible Alarm	Battery Mode	Beeping every 4 seconds (re-settable) and every second when battery low
	Overload	Beeping twice every second
	Fault	Beeping Continuously
Communications		RS-232 Interface,With monitoring software,USB Option,SNMP NetAgent Option
Surge protection		RJ-45 I/O port available for network or Fax/Modem
Environment	Working temperature	- 20ºC~40ºC
	Humidity	0-95% non-condensing
Product size	WxDxH (mm)	405145220	405145220
Package dimension	WxDxH (mm)	505485345/2PCS	505485345/2PCS
Product weight	Kg/PCS	26/2PCS	27/2PCS
Optional	Battery Cabinet	BX-37	N/A
REMARK		* CK-RTX --- Standard Type, CKS-TX---- Long Time Type.

Product Show:
