Cast Iron Frame - Dahlander 8/4 Pole - Constant Torque Motor

Name: Cast Iron Frame - Dahlander 8/4 Pole - Constant Torque Motor
Brand: all-electronics-online.com
SKU: 721825465
Availability: InStock
Rating: 4.3 (88 reviews)

Price:	US $ 95/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	50/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	YD
Markets:	South America,Africa,Mid East
Warranty:	12 Months
Application:	Universal
Operating Speed:	Adjust Speed
Number Of Stator:	Three-Phase
Rotor Structure:	Squirrel-Cage
Casing Protection:	Closed Type
Starting Mode:	Direct on-line Starting
Species:	Yd Double Speed
Number Of Poles:	8/4 2/4
Brand:	Yinda

Product Description

Dahlander 8/4 Pole - Constant Torque Electric Motor

Typical applications

Pumps
Fans
Crushers
Conveyor belts
Mills
Centrifugal machines
Presses
Elevators
Packaging equipment
Grinders and others

Standard Features

Three-phase, IP44, TEFC
Number of Poles: 4/2
Frames: 71 up to 315S/M
Mounting: B3
Voltage: 380 V
Class "F" insulation (ΔT = 80K)
Continuous duty: S1
Ambient temperature: 40 °C, at 1000 m.a.s.l
Squirrel cage rotor / Aluminium die cast
Color: RAL 5010 - Blue

*For additional details about Inverter operation, please contact our technical support.

Optional Available

Frequency: 60 Hz
Other voltages
Class "F" insulation;
Thermal protection:
Double shaft end
Encoder

More options available, on request

Technical Data

YD80M1--4/2	0.45/0.55	380	1.4/1.5	1400/2750	66/65	0.74/0.85	6.5/7	1.5/1.7	79
YD80M2--4/2	0.55/0.75	380	1.7/2.0	1400/2750	68/66	0.74/0.85	6.5/7	1.6/1.8	79
YD90S--4/2	0.85/1.1	380	2.3/2.8	1410/2830	74/71	0.77/0.85	6.5/7	1.8/1.9	79
YD90L--4/2	1.3/1.8	380	3.3/4.4	1410/2830	76/73	0.78/0.85	6.5/7	1.8/2.0	83
YD100L1--4/2	2/2.4	380	4.8/5.6	1430/2850	78/76	0.81/0.86	6.5/7	1.7/1.9	87
YD100L2--4/2	2.4/3	380	5.6/6.7	1430/2850	79/77	0.83/0.89	6.5/7	1.6/1.7	87
YD112M--4/2	3.3/4	380	7.4/8.6	1445/2890	82/89	0.83/0.89	6.5/7	1.9/2.0	87
YD132S--4/2	4.5/5.5	380	9.8/11.9	1450/2855	83/79	0.84/0.89	6.5/7	1.7/1.8	91
YD132M--4/2	6.5/8	380	13.8/17.1	1450/2880	84/80	0.85/0.89	6.5/7	1.7/1.8	91
YD90S--6/4	0.65/0.85	380	2.3/2.3	920/1410	64/70	0.68/0.79	6/6.5	1.6/1.4	75
YD90L--6/4	0.85/1.1	380	2.8/3.0	930/1410	66/71	0.7/0.79	6/6.5	1.6/1.5	75
YD100L1--6/4	1.3/1.8	380	3.8/4.4	940/1440	74/77	0.70/0.80	6/6.5	1.7/1.4	78
YD100L2--6/4	1.5/2.2	380	4.3/5.4	940/1440	75/77	0.70/0.80	6/6.5	1.6/1.4	78
YD112M--6/4	2.2/2.8	380	5.7/6.7	950/1430	78/77	0.75/0.82	6/6.5	1.8/1.5	82
YD132S--6/4	3/4	380	7.7/9.5	970/1440	79/78	0.75/0.82	6/6.5	1.8/1.7	82
YD132M--6/4	4/4.5	380	9.8/12.3	970/1450	82/80	0.76/0.85	6/6.5	1.6/1.4	82
YD90L--8/4	0.45/0.75	380	1.9/1.8	670/1400	58/72	0.63/0.87	5.5/6.5	1.6/1.4	75
YD100L--8/4	0.85/1.5	380	3.1/3.5	750/1514	67/74	0.63/0.88	5.5/6.5	1.6/1.4	78
YD112M--8/4	1.5/2.4	380	5.0/5.3	710/1430	72/78	0.63/0.88	5.5/6.5	1.7/1.7	82
YD132S--8/4	2.2/3.3	380	7.0/7.1	720/1445	75/80	0.64/0.88	5.5/6.5	1.5/1.7	82
YD132M--8/4	3/4.5	380	9.0/9.4	720/1450	78/82	0.65/0.89	5.5/6.5	1.5/1.6	82
YD90S--8/6	0.35/0.45	380	1.6/1.4	675/930	56/70	0.60/0.72	5/6	1.8/2	73
YD90L--8/6	0.45/0.65	380	1.9/1.9	680/920	59/71	0.60/0.73	5/6	1.7/1.8	73
YD100L--8/6	0.75/1.1	380	2.9/3.1	710/945	65/75	0.60/0.73	5/6	1.8/1.9	73
YD112M--8/6	1.3/1.8	380	4.5/4.8	710/945	72/78	0.61/0.73	5/6	1.7/1.9	75
YD132S--8/6	1.8/2.4	380	5.8/6.2	725//970	76/80	0.62/0.73	5/6	1.6/1.9	79
YD132M--8/6	2.6/3.7	380	8.2/9.4	725/970	78/82	0.62/0.73	5/6	1.9/1.9	79
