Cwf-S29 Threaded Type Stainless Steel Probe PT100 Temperature Sensor
| Price: |
US $ 0.1-8.9/Piece |
| Min Order: |
1000/Piece |
| Pay Type: |
L/C,T/T |
| Prod Model: |
WD-TS006 |
| Resistance Accuracy: |
±0.012% |
| Measurement Current: |
0.1mA |
| Insulation Resistance: |
>10mΩ |
| Operation Temperature: |
-50c~+250c |
| Sensor: |
PT100 |
Product Description
Stainless Steel Probe PT100 Temperature Sensor
The Product Sells Point:
*Very Precise Measuring: Measuring Temperature ±0.5ºC
*Precise linear Temperature-Resistance Characteristic.
*Low Weight
*Short response Time
KEY Specifications/Features:
*Nominal Resistance; 100Ω at 0ºC
*Basic Thermistor Values: for Platinum Measuing Resistors as in Chart
*Measuring Range;-40C to 350C, other ranges on request
*Measuring Current; Max ImA (No Self-heating)
Circuit: 2 Wire, 3-wire or Customized.
Features:
*Straight Probe Assembly, Cable Runs directly to the sensing Element
*Contains a precision 100 Ohm Class B DIN Platinum Element
*Compact Design for OEM RTD Sensor Probe Applications
*Available in 1/4", 3/16", 1/8" 3mm, 4.5mm and 6mm Diameters, and Various Lengths
*2-3-4 wire PFA insulated, PFA Jacketed Cable
*Also Available with Fiberglass insulated cables, fiberglass cable with SST Overbraid or Fiberglass Cables, with BX Amored Hose
MORE OPTIONS:
| Type | Measuring Range ºC | Accuracy | Tolerance |
| PT100 | -50~+500 | Class A | ±(0.15+0.002) |
| Class B | ±(0.30+0.005) |
| PT1000 | -50~+500 | Class A | ± (0.15+0.002) |
| Class B | + (0.30+0.005) |
| | | | |
| Construction | Water Proof/Abrasion-Proof/Anti-explosion |
| Cable | 2-Wire, 3-Wire, 4-Wire |
| Cable material | PVC Cable, Silic Cable, TPE Cable, PTFE Cable |
| Wyas of mounting & Fixing | 1.Without fixing device
2.Fixed Compression Thread |
*
