Danfoss Rt Temperature Switch Rt101 (017-515566) Differential Switch Differential Controller

Name: Danfoss Rt Temperature Switch Rt101 (017-515566) Differential Switch Differential Controller
Brand: all-electronics-online.com
SKU: 715412445
Availability: InStock
Rating: 4.3 (37 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	RT101 ( 017-515566 )
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Usage:	Refrigerator
Type:	Temperature Controller

Product Description

RT101 ( 017-515566 ) differential switch differential controller

Product Description

The RT series includes temperature controls and pressure controls for general applications within industrial and marine refrigeration. An RT temperature controls is fitted with a single-pole changeover switch. The position of the contacts depends on the sensor temperature and the set scale value. An RT pressure control contains a pressure operated single-pole changeover contact, the position of which depends on the pressure in the inlet connection and the set scale value.
Product Features
Enclosure: IP66 to EN 60529 / IEC 60529, except for versions with ext
reset which are to IP54
Insulation 400 V
Ambient temperature: -50 - 70 °C for housing
Cable connection: Pg 13.5
Cable diameter: 6-14 mm
Pressure controls for fluorinated refrigerants and R717 (NH3)

RT Series switches for general industrial applications and marine applications.

RT temperature switch series consists of a series of conventional temperature control switch and temperature switch with remote sensors, including the neutral zone temperature switches.

RT temperature switch is usually applied with a high degree of security or energy requirements of the application.

Code	Type
RT
017-515566	Temperature Control RT 103 with capillary bulb sensor 10-45C
017-519866	Temperature Control RT 115 with capillary bulb sensor 10-35C
017-523666	Temperature Control RT 140 with capillary bulb sensor 15-45C,2m
017-524166	Temperature Control RT 141 with capillary bulb sensor 40-80C,2m
017-500366	Temperature Control RT 101 with bulb sensor 25-90C,2m
017-500466	Temperature Control RT 101 with bulb sensor 25-90C,2m,Maximum reset
017-500566	Temperature Control RT 101 with bulb sensor 25-90C,2m,BC,Sealing cap
017-500666	Temperature Control RT 101 with bulb sensor 25-90C,3m
017-502266	Temperature Control RT 101 with bulb sensor 25-90C,5m
017-502366	Temperature Control RT 101 with bulb sensor 25-90C,5m,Maximum reset
017-502466	Temperature Control RT 101 with bulb sensor 25-90C,8m
017-502566	Temperature Control RT 101 with bulb sensor 25-90C,10m
017-503366	Temperature Control RT 101 with bulb sensor
017-150066	Temperature Control RT 101 with bulb sensor
017-151066	Temperature Control RT 101 with bulb sensor factory set
017-514766	Temperature Control RT 102 with capillary bulb sensor
017-151566	Temperature Control RT 101 with bulb sensor 120-215,Maximum reset/ip
017-504866	Temperature Control RT 106 with bulb sensor 25-90C,2m
017-504966	Temperature Control RT 106 with bulb sensor 25-90C,2m,BC,Sealing cap
017-505066	Temperature Control RT 106 with bulb sensor 20-90C,5m
017-505166	Temperature Control RT 106 with bulb sensor 20-90C,3m,BC,Sealing cap
017-513566	Temperature Control RT 107 with bulb sensor
017-513666	Temperature Control RT 107 with bulb sensor 70-150C,2m,Maximum reset
017-513766	Temperature Control RT 107 with bulb sensor 70-150C,2m,BC,Sealing cap
017-513966	Temperature Control RT 107 with bulb sensor 70-150C,3m
017-514066	Temperature Control RT 107 with bulb sensor 70-150C,5m
017-514166	Temperature Control RT 107 with bulb sensor 70-150C,5m,Maximum reset
017-514366	Temperature Control RT 107 with bulb sensor 70-150C,5m,BC,Sealing cap
017-514466	Temperature Control RT 107 with bulb sensor 70-150C,8m
017-514566	Temperature Control RT 107 with bulb sensor 70-150C,10m
017-150166	Temperature Control RT 107 with bulb sensor
017-506066	Temperature Control RT 108 with bulb sensor 30-140,2m
017-520566	Temperature Control RT 120 with bulb sensor 120-215C,2m
017-520666	Temperature Control RT 120 with bulb sensor 120-215C,5m
017-520766	Temperature Control RT 120 with bulb sensor 120-215C,8m
017-520866	Temperature Control RT 120 with bulb sensor 120-215C,2m
017-520966	Temperature Control RT 120 with bulb sensor 120-215C,5m
017-521166	Temperature Control RT 120 with bulb sensor 120-215C,2m,Maximum reset
017-521266	Temperature Control RT 120 with bulb sensor
017-521466	Temperature Control RT 120 with bulb sensor 120-215C,2m,Maximum reset
017-152366	Temperature Control RT 120 with bulb sensor 120-215C,2m,Maximum reset/IP
017-152466	Temperature Control RT 120 with bulb sensor Maximum reset
017-522066	Temperature Control RT 123 with bulb sensor 150-250C,2m
017-522266	Temperature Control RT 123 with bulb sensor 150-250C,5m
017-522466	Temperature Control RT 123 with bulb sensor 150-250C,2m,Maximum reset
017-152266	Temperature Control RT 123 with bulb sensor 150-250C,2m/IP
017-522766	Temperature Control RT 124 with bulb sensor
017-522966	Temperature Control RT 124 with bulb sensor 200-300C,5m
017-523166	Temperature Control RT 124 with bulb sensor 200-300C,Maximum reset
017L002466	Temperature Control RT 16L with intermediate zones
017L003166	Temperature Control RT 140L with intermediate zones 15-45C,2m
