Dynamometer with Wireless Indicator/ Remote Display 10 Tons

Prod Model:	dynamometer with wireless indicator
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Usage:	Dynamometer

Product Description

Dynamometer with wireless indicator / remote display 10 tons

wireless dynamometer is an extremely well-built instrument for industry use ,as a standard wireless tool offer universal applications,Whether used as conventional crane weigher or to measure force, the wireless dynamometer is the latest design, compatible with the concept of portable, print and easy to operate. Shoulder bag style leather case,easy to carry, suitable for protected outdoor use., calibration is easier with 580 indicator.


Body protection: Aluminum and alloy steel capacities are powder coated.
Accuracy:  0.05% for 1-50t, 0.1% for above 50t capacity.

Units:  Units are clearly display on the screen, available in the following measurment reading: kilograms(kg), short Tons(t) pounds(lb), Newton and kilonewton(kN)

Shackles:  High tension industrial standard G2130 anchor shackle bows, galvanized finish.

Gravity regulation:  The acceleration of gravity can be regulated through indicator parameter setting according to different places value.

Functions: wireless indicator with many functions: Zero, tare, Low battery warnings, peak hold, overload warning. User calibration(with password).

Set-Point: Two user programmable Set-Point can be used for safety and warning applications or for limit weighing.

Body indicator key:  4 local mechanical keys:"ON/OFF","ZERO","PEAK" and "Unit Change".

Indicator communications:  Both RS232 serial port and USB port,solve most laptopswithoutserial portproblem. with the Everight company's PC host computer software,not only display weigh value and stable information on the PC ,can also enter company's name,complete storage ,print query and other functions .

Antenna: Internal antenna

Function on indicator keyboard:  It can print data,time,Serial number, commodity number,net weight and total weight. Also can input 16 digits head information,It can store up to 2000 weighing records.It can be statistics by serial number or commodity number,also can statistics by data, statistical results can be printed with weighing number and total weight.

Model list

Type	Max testing load (kg)	Min testing load (kg)	Division value  (kg)	scale division (n)
HY-W-01(1T)	1000	10	0.5	2000
HY-W-02(2T)	2000	20	1	2000
HY-W-03(3T)	3000	20	1	3000
HY-W-05(5T)	5000	40	2	2500
HY-W-10(10T)	10000	100	5	2000
HY-W-20(20T)	20000	200	10	2000
HY-W-30(30T)	30000	200	10	3000
HY-W-50(50T)	50000	400	20	2500
HY-W-100(100T)	100000	1000	50	2000
HY-W-150(150T)	150000	1000	50	3000
HY-W-200(200T)	200000	2000	100	2000
