Fiber Optic Single Mode OS2 E2000 APC to E2000 APC Connector Patch Cable

Name: Fiber Optic Single Mode OS2 E2000 APC to E2000 APC Connector Patch Cable
Brand: all-electronics-online.com
SKU: 819203005
Availability: InStock
Rating: 4.7 (60 reviews)

Price:	US $ 3-3.7/Piece
Min Order:	1/Piece
Pay Type:	T/T,D/P,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	PN-009
Cable:	2.0mm
Color:	Yellow
Connector:	E2000
Fiber Type:	APC, UPC
Length:	1 meter
Application:	Communication
Type:	Single-mode Fiber
Certification:	ISO9001
Connection Structure:	E2000
Sheath Material:	Plemun

Product Description

Fiber Optic Single Mode OS2 E2000 APC to E2000 APC Connector Patch Cable

The 9/125μm Single-Mode fiber patch cable meets RoHS compliant, and all cables are 100% optically tested for insertion loss to ensure high quality, it is very cost-effective for network cabling. PUNO also provides a full set of OEM services, such as fiber connector, length, color, fiber grade, specification, material, package etc.

Keyed Characteristics:

RoHS Compliant;
Standard & custom configurations;
Meets Telecordia-GR-326-CORE standards;
Easy installation;
Environmentally stable;
Low insertion loss, high return loss;
Ultra low back reflection;
For 3.0mm, 2.4mm, 2.0mm jacket or 900um buffer;
Single mode fiber: ITU - T G. 652D;
Multi mode fiber: ITU - T G. 651;
Fiber Min. Bending radius: 10D (Static).

Application:

High bit rate data transmission;
Telecommunication networks;
Data processing networks;
Metro applications;
Testing instruments;
Military, medical and industrial;
Active device termination;
CATV system;
Active device terminations;
LAN / WAN;
FTTx (including FTTB, FTTC, FTTD, FTTH).

Specifications:

Connector	SC,FC,LC,ST,MU,E2000,MT-RJ
Polishing	SM/UPC	MM/PC	SM/APC
Insertion Loss(max)	≤0.30dB	≤0.25dB	≤0.30dB
Return Loss(min)	≥50dB	≥35dB	≥60dB
Tensile Strength	>6N
Durability	<0.20 dB typical change, 1000 matings
Repeatability	≤0.1dB
Storage / Operating Temperature	-40ºC ~ +85ºC

Features:
(1) Meets Telcordia GR-326 Core and ROHS requirements;
(2) The connector could be SC,FC,LC,ST,MU,E2000, MT-RJ etc;
(3) The cable could be G652D,G655,G657,OM1,OM2,OM3 etc;
(4) The cable size could be 1.2×2.5mm, 1,6×3.3mm, 2.0×4.1mm,2.8×5.7mm etc.
