Handwave Infrared Sensor (2053.102N) , Touchless Hand Switch for Automatic Door

Prod Model:	2053.102N
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power Supply:	DC12-24V
Static Power Consumption:	62mA
Current Action:	115mA
Induction Distance:	1-20cm

Product Description

Infrared handwave sensor (2053.102N)

Infrared handwave sensor Features:
*Modulation and demodulation using infrared, and will not interfere with the jamming signal.
*Hand (or reflective objects) positive for contact sensors, clean health, prevent pollution hand.
*Induction distance flexible adjustable for different occasions-configurable.
*Use low-power design, equipment service life longer.
*Imports of high sensitivity to the infrared infrared sensor timely and convenient manner.
*Hidden-specific emergency button, and if induction fault, but also by emergency button to open automatic doors (or outside), to ensure that equipment failure-free operation.
*Automatic door contact with dry signal output can be directly used for automatic doors open.
*Feelings went Optical instructions; Positive hidden screw fixation; Satin patch designs.

Infrared handwave sensor Technical parameters:
Power supply: DC12V or DC24V (ordering equipment should statement)
Static power consumption: 62 mA current action: 115 mA
Induction distance: 1 ~ 20 CM adjustable.
Modulation and demodulation frequency: 38KHZ
Induction: Active Infrared Reflectance
Surface Composition: Imports scrub patch
Working environment Humidity: 10 to 90% RH
Operating temperature range: -20*C ~ +45*C
Size: 115 mm (L) * 75mm (W) * 15mm (H)
Fixed: Fixed positive hidden screws
