High Frequency Online UPS (JD-MSW 75-200W)

Name: High Frequency Online UPS (JD-MSW 75-200W)
Brand: all-electronics-online.com
SKU: 839728215
Availability: InStock
Rating: 4.5 (87 reviews)

Price:	Negotiable/Piece
Min Order:	50/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	JD-MSW 75-200W
Principle Of Work:	Vector Control Transducer
Switch Mode:	PWM Control
Main Circuit Type:	Voltage
Application:	General Transducer, High-Performance Transducer

Product Description

High Frequency Online UPS (JD-MSW 75-200W) Key Features
1 High frequency DC-AC power inverter

2 Single phase modefied sine wave ouput

3 Full range protection for the inverter and the battery.

4 With USB port

5 Smaller and light

6 Modified sine wave

7 LED display and alarm

8 Two times surge power.

Technical Specifications

Mode	JD 75U	JD75DA	JD150Y	JD150DA	JD175U	JD200U	JD200Y
Continuous power (W)	75	150	150	150	175	200	200
Surge capability (W)	150	300	300	300	350	400	400
DC input (VDC)	12V
DC input range	10.5V to 15.5V±0.3
AC output	220V,110V ±10 V
Output frequency	50/60±5 HZ
Output waveform	Modified sine wave
Efficiency	>85%
Battery low alarm	10.2-10.8V
Over discharge protection	10 ±0.5V, shut off
Resume voltage	11.7V--12.8V ,auto restart
Over voltage protection	15V-16.5V ,shut off.
Overload protection	Shut off while over 120% rated capacity
With cooling fan	Yes
USB	Yes
DC conection	Cigarette lighter
Connection convertor	No
Product package	Blister
Running temperature	20 to 40 degree
High temperature protection	Yes
Short circuit protection	Yes
Reverse polarity protection	Yes
Product size(mm)	11557.537	1457550	Φ70*145	1457550	1417450	1006743	Φ70*145
Carton size (mm)	475290570	515355370	440410360	515355370	540390375	475290570	440410360
Carton weight (kg)	12	13	14	13	11	16	14
PCS /CTN	50	40	30	40	40	40	30

Product Show:

Trade Show:

Certification:
