High Quality Insulated Ring Terminals (EN Series)

Prod Model:	EN Series
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Cable Sq. Mm.:	1.5,2.5,4,6,10,16
Stud Hole E:	4.2,5.2,6.5,4.2
Feature:	High Wall Thickness, Giving Termination
Finish:	Electro-Tin Plated for Operating Temperature 150
Type:	Socket Terminals
Material:	Copper
Application:	Transmission of Electrical Signals
Brand:	Eleco

Product Description

Application

Item No.	Dimension					A.W.G	mm2
	L(mm)	D(mm)	C(mm)	B(mm)	W(mm)
EN0506	6.0	1.3	1.0	0.7	2.1	#22	0.5
EN75.6	6.0	1.5	1.2	0.7	2.5	#20	0.75
EN1006	6.0	1.7	1.4	0.7	2.7	#18	1.0
EN1010	10.0
EN1507	7.0	2.0	1.7	1.0	3.5	#16	1.5
EN1510	10.0
EN2507	7.0	2.5	2.2	1.0	2.5	#14	2.5
EN2512	12.0
EN4009	9.0	3.2	2.8	1.0	4.0	#12	4.0
EN4012	12.0
EN6010	10.0	3.9	3.5	1.0	4.8	#10	6.0
EN6012	12.0
EN6015	15.0
EN10-12	12.0	4.9	4.5	1.2	5.8	#7	10.0
EN10-15	15.0
EN10-18	18.0
EN16-12	12.0	6.2	5.8	1.5	7.5	#5	16.0
EN16-15	15.0
EN16-18	18.0
EN25-16	16.0	7.9	7.5	1.8	9.2	#4	25
EN25-22	22.0
EN35-16	16.0	8.7	8.3	2.0	10	#2	35
EN35-25	25.0
EN50-20	20.0	10.9	1.3	2.0	12.4	#1	50
EN50-25	25.0
