Shenzhen Sunshine LED Limited >> LED Touch Panel Dimmer/Controller Wireless Remote Control

LED Touch Panel Dimmer/Controller Wireless Remote Control

LED Touch Panel Dimmer/Controller Wireless Remote Control
Price: US $ 19set
Trade Terms: FOB,EXW
Min Order: 5set
Pay Type: T/T,Western Union,Paypal
Prod Model: SU-CON-TOUCH-LV
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product Name: LED Controller
Size(Mm): L74*W50*H29
Suply Voltage: 12V, 24V
Output Current: 8A*3CH(12V) / 4A*3CH(24V)
Output Power: 216W(12V) / 288W(24V)
Frenquency: 433.92MHz
Polarity: Common Anode
Model Number: Su-Con-Touch-LV
Output: 3/1 Channel
Brand: Sunshine
Application: Audio / Video Players
Signal Transmission: WiFi Singnal
Type: Controller

Product Description

Input 12V/24V LED Touch Panel Controller, Dimmer

Compatible with any LED RGB product, Unique touch technology, user-friendly operation and easy to use


Automatically adapt to LED light which works at DC12V or DC24V. The touch ring is used for easy color access


There are 4 predefined pattern modes with static color, gradual, hopping and white light

Technical Specification

1. Frenquency: 433.92MHz

2. Input Voltage: 12V / 24V

3. Output Current: 8A*3CH(12V) / 4A*3CH(24V)

4. Output power: 216W(12V) / 288W(24V)

5. Polarity: Common anode


Function Description

1.4 predefined patterns, including static color, gradual, hopping and white light

2. Brightness, color and speed control

3. Power-lost memory recovery function

4. Touch surface with full color selection ring

Keys Function Description

1. Power OFF

2. Power ON / Mode change

3. Speed+, static color saturation increase, white mode invalid

4. Speed-, static color saturation decrease, white mode invalid

5. Color ring, gradient mode and white mode invalid

6. BRT+, brightness increase

7. BRT-, brightness decrease

8. Indicator


Remote Address Learning

1. Load remote controller with batteries, touch the BRT-key close the indicator

2. Power on receiver, all 3 indicators light, touch the power ON key within 5 seconds

3. The receiver`s indicator light turns blue, the remote address learning success


Advantage:

1. Match with the RGB flexible strip, easily control the colors change

2. Wireless touching remote and control distance is more than 30meters

3. Two kinds of modes: Gradual change mode and hopping change mode.

4. The rate of color change and the brightness can be easily control

5.3 kind of wireless remoter, you can choose as you like.

6: 2 years warranty, fast delivery time


Connection

Our service

1. Your inquiry related to our products or prices will be replied in 24hours.

2. Well-trained and experienced staffs to answer all your enquires in fluent English

3. OEM and ODM, any your custonized lightings we can help you desiign put into product

4. Distributonership are offered for your unique design and some our current models

5. Protection of your sales area, ideas of design and all your private information

Pament Terms:

T/T, West union, Paypal is availiable for us.

Should any questions, Pls add my skype or give me an inquiry, So I can service you better, also you can get more information for our COB Downlight, Happy shopping! !

Contact: Rachel Lee
Mobile no: +86-15999511752
Phone no: +86-755-89564062
Touch Panel LED Controller
SU-TM07 Touch Panel Color Temperature
controller
12V, 24V  <4A 12V<96W 24V<192W L86×W86×H36mm
SU-TM06 Touch Panel Dimmer 12V, 24V  <8A 12V<96W 24V<192W L86*W86*H36mm
SU-TM05 Touch Panel Three Key Dimmer 12V, 24V  <8A 12V<96W 24V<192W L86*W86*H36mm
SU-TM04 Touch Panel Hand dimmer 12V, 24V  <8A 12V<96W 24V<192W L86*W86*H36mm
SU-TM03 Touch Panel Six Key Controller 12V, 24V  <4A 12V<144W 24V<288W L86*W86*H36mm
SU-TM02 Touch Panel Four Key Controller  12V, 24V  <4A 12V<144W 24V<288W L86*W86*H36mm
SU-TM01 Touch Panel Multi-function Controller 12V, 24V  <4A 12V<144W 24V<288W L86*W86*H36mm
SU-TM08 Touch Panel Full-color Controller 12V, 24V <4A 12V<144W 24V<288W L74ΧW50ΧH29mm
SUNSHINE LED LIMITED, which is a new high-tech enterprise engaged in research, manufacturing and marketing of LED light. The main products involve LED Strip, SMD5050 LED Strip, RGBW LED Strip, SMD3014, SMD3528, SMD5630, SMD2216 LED Strip, and RGB or RGBW LED Downlight and LED Controller and LED accessories etc, all of which are widely used for urban lighting decoration, indoor home decoration, hotel decoration, stage lighting, signal lamp, road lighting and other areas.

Sunshine covers more than 3500 square meters with completed equipments, 75 workers uses high level Auto-production Machines for SMT assembly and soldering. Our strip series' monthly capacity is above 50, 000 meters and the RGB or RGBW LED Downlight monthly capacity is above 5, 000PCS. All the products must have 100% life testing before shipment. Because of efficient production & quality control, Sunshine has already got good honor & accreditation from the customers. Our products are sold to America, Denmark, Australia, Japan, France and all districts of our country.

We have passed ISO9001, CE and SGS certifications. Through persevering efforts, we have become one of the largest suppliers in LED light field in China and also won the trust of our customers because of excellent quality and prompt delivery.

Choosing Sunshine means choosing satisfaction and choosing benefit! We firmly believe "Technology changes the world and the world will be more brilliant because of Sunshine
