Model LC1-Y Series Energy Saving AC Contactor

Name: Model LC1-Y Series Energy Saving AC Contactor
Brand: all-electronics-online.com
SKU: 747556415
Availability: InStock
Rating: 4.9 (50 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CIF
Min Order:	50/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	LC1-Y
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Theory:	Electromagnetic Relay
Rated Voltage:	1000V
Rated Current:	1000A
Model:	LC1-Y

Product Description

Application
LC1-Y Energy Saving AC contactor is applicable in the circuits up to the rated voltage 1000V, AC 50Hz or 60Hz, rated current up to 1000A, for long distance switching on and breaking circuit and frequently starting or control AC motor. It can form electromagnetic starter with thermal overload relay or electronic protector. It can also protect overload or open-phase current, and form reversing interlock conversion contactor, power-distribution conversion contactor and star-delta starter.

Advantages
A. Power saving: 5% of traditional power consuming.
B. Long life: Short arc duration, little contact ablation, contact does not quiver when voltage fluctuates.
C. Reliable: Coil does not burn.
D. No noise.
E. Coil control, no temperature rising.
F. Not influenced by network voltage fluctuation.

Model	Rated operation voltage 380V	Rated thermal current	Three phase electromotor rated power		Suitable thermal relay
	AC3 le/A	AC1 lth/A	AC3 380V 50Hz
	AC3 le/A	AC1 lth/A	kW	Hp-ch
LC1-Y115	115	200	55	75	JR28-200
LC1-Y150	150	250	75	100	JR28-200
LC1-Y185	185	275	90	125	JR28-200
LC1-Y225	225	315	110	150	JR28-630
LC1-Y265	265	350	132	180	JR28-630
LC1-Y330	330	400	160	220	JR28-630
LC1-Y400	400	500	200	280	JR28-630
LC1-Y500	500	700	250	335	JR28-630
LC1-Y630	630	1000	335	450	JR28-630

Long Road Electric Co. Ltd founded in 2010, is located in the largest manufacturing base of low-voltage electric equipment of Wenzhou China, which is called "the Electric Device Metropolis of China". Long Road Electric specialized in the SMC, DMC and PLASTIC materials energy meter boxes Manufacturing, International trade and service.

Long Road Electric Co, Ltd regards quality of products as life, Longroad Electric Co., Ltd has been granted ISO9001 management system certifications. The comprehensive product line has more than 100 models which have been approved by TUV, CE, CB, SGS, RoHS, SASO. The products sells well to UK, Spain, Portugal, Singapore, Turkey, Russia, Korea, South Africa, Nigeria etc...More than 70 countries and regions.

Long Road Electric Co. Ltd is always striving hard to provide the best services and competitve pricing to all customers.
