| Prod Model: |
MP |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
MP2 |
| Thermal Protection Adjustment Range: |
0.1-80A |
| Motor Power: |
up to 63A at 690 VAC |
| Mounting Mode: |
by Clips or Screws |
| Mounting Support: |
DIN Rail |
| Mounting Position: |
Horizontal / Vertical |
| Control Type: |
Pushbutton |
| Breaking Capacity: |
Low Voltage Circuit Breakers |
| Operation: |
Manual Type |
| Speed: |
Normal Type Circuit Breaker |
| Arc-extinguishing Medium: |
Air |
| Installation: |
Fixed |
| Structure: |
MCB |
| Poles Number: |
1 |
| Certification: |
CE |
Product Description
Specification
| Type | Rated Standard ppower of 3-phase
motors 50/60Hz in category AC-3 | Setting range |
| 220V | 380V | 415V | 440V | 500V | 660V |
| kW | kW | kW | kW | kW | kW |
| MP2-M01 | - | - | - | - | - | - | 0.1-0.16 |
| MP2-M02 | - | - | - | - | - | - | 0.16-0.25 |
| MP2-M03 | - | - | - | - | - | - | 0.25-0.4 |
| MP2-M04 | - | - | - | - | - | 0.37 | 0.4-0.63 |
| MP2-M05 | - | - | - | 0.37 | 0.37 | 0.55 | 0.63-1 |
| MP2-M06 | - | 0.37 | - | 0.55 | 0.75 | 1.1 | 1-1.6 |
| MP2-M07 | 0.37 | 0.75 | 0.75 | 1.1 | 1.1 | 1.5 | 1.6-2.5 |
| MP2-M08 | 0.75 | 1.5 | 1.5 | 1.5 | 2.2 | 3 | 2.5-4 |
| MP2-M10 | 1.1 | 2.2 | 2.2 | 3 | 3.7 | 4 | 4-6.3 |
| MP2-M14 | 2.2 | 4 | 4 | 4 | 5.5 | 7.5 | 6-10 |
| MP2-M16 | 3 | 5.5 | 5.5 | 7.5 | 7.5 | 9 | 9-14 |
| MP2-M20 | 4 | 7.5 | 9 | 9 | 9 | 11 | 13-18 |
| MP2-M21 | 5.5 | 11 | 11 | 11 | 11 | 15 | 17-23 |
| MP2-M22 | 5.5 | 11 | 11 | 11 | 15 | 18.5 | 20-25 |
| MP2-M32 | 7.5 | 15 | 15 | 15 | 18.5 | 26 | 24-32 |
| MP3-M25 | 5.5 | 11 | 11 | 11 | 15 | 18.5 | 16-25 |
| MP3-M40 | 11 | 18.5 | 18.5 | 22 | 25 | 33 | 25-40 |
| MP3-M63 | 15 | 30 | 33 | 33 | 40 | 55 | 40-63 |
| MP3-M80 | 22 | 40 | 45 | 45 | 55 | 63 | 56-80 |
Application
MP series motor protection circuit breakers are mainly used for the overload and shor tcircuit protection of the motor in AC 50/60Hz, up to 660V, 0.1-80A power circuit, as full-voltage starter to start and cut off the motor, under the AC3 load or for the overload and short circuit protection of the circuit and power equipment in the power distribution network.
