| Prod Model: |
MT500VA |
| Input: |
110V or 220V +- 20% |
| Output;: |
110V or 220V+ - 10% |
| Wave Form: |
Transfer Time Less Than 10ms. |
| Output PF: |
0.6 |
| Phase: |
Single Phase |
| Type: |
Line Interactive |
| Protection: |
Short Circuit |
| Classification: |
UPS |
| Brand: |
Kemapower |
Product Description
MT500VA Line Interactive UPS * I/P: 165~265V±5V or 88 - 139V ,O/P:2220V or 110V ± 10%
* Wave Form:Modified sine wave
* Transfer Time:<10 ms
* DC Voltage: 500VA /12VDC
* Bat.:500VA /12V External
Key features:1.Line-interactive UPS with super-long backup time
2.wide input range with AVR function
3.Protection for short circuit, overload and battery low voltage
4.LED indication and audible alarm function
5.Intelligent battery management
6.with cold start function
7.with AUTO restart function
8.Automatic battery charging while UPS off mode ( Option)
9.RJ11/RJ45 is option
Technical Specifications | ITEM | MODEL | MT 500S |
| Capacity | Output power | 500VA/300W |
| Input | Voltage range | 165~265Vac±5V or 88 - 139Vac |
| Frequency range | 50 or 60 ± 2.5Hz |
| Output | Voltage(bat mode) | 220V or 110V ± 10% |
| Frequency (ba mode) | 50 / 60HZ or ± 10% |
| Transfer time | <10Ms |
| Waveform | Modified sine wave (battery mode) |
| Battery | Type | Sealed lead acid, maintenance free |
| DC voltage | 12VDC |
| Battery number | 12VDC External |
| Standby time | Depended on battery capacity |
| Recharge time | 12VDC3.5AMP |
| Protecting | Output overload | Fuse & current limited when overloaded |
| Battery low voltage | Automatically lock out the machine so as to protect the Battery from over discharging |
| Short circuit | Fuse & current limited |
| Restart | Auto restart when AC recovery. |
| Alarm | Battery back-up | Sounding every 4 seconds |
| Battery low | Sounding every 1 second |
| Overload | Shutdown at once |
| Indicator | LED | Line Mode, Battery Mode, Charging, battery capacity, Fault |
| PCS/ CTN | | 2PCS |
| Carton size | L*W*H(mm) 2PCS | 505*485*345/2PCS |
| Carton Gross weight | Kg, 2PCS | 17Kg |
