NEMA17 Hybrid Stepper Servo Motor

NEMA17 Hybrid Stepper Servo Motor
Price: US $ 50-55/Piece
Min Order: 50/Piece
Pay Type: T/T
Prod Model: Hs421
Size: 42mm
Resistance: 100min 500VDC
Tem.: 0-55
Number Of Stator: Two-Phase
Excitation Mode: HB-Hybrid
Type: Magnetic-Electric
Speed: 0-3000rpm
Certification: ISO

Product Description

I.CH Motion Hybrid Stepper Servo Motor HS421
General Specifications

Speed:0-3000RPM
Insulation Resistance:100MIN,500VDC
Ambient Temperature:(0-55ºC)
Encoder lines:2500/1000


Electrical Specification
Series ModelRated Voltage  (V)L
(mm)
Phase Current   (A)Phase
Resistance
(Ω)
Phase
Inductance(mH)
Holding Torque
(N.cm)
Moment of Inertia   (g.cm2)Motor
Weight
( g)
HS421-05013A4.16511.33.25.55077530
HS421-05023A2.3512.31.01.95077530
HS421-05613A4.94671.33.88.556115670
HS421-07023A3.22672.31.43.170115670

Mechnical Drawing


Learwire Drawing



I. CH MOTION is specialized in researching, developing and serve electric motor in China. With the professionalism of our highly trained and qualified mechanical engineers, electronic engineers and marketing consultants, we are able to provide product design and integration service to our customers in the world market.

We supply a complete range of electrical/electronic motors including AC motors, AC Gear motor, DC motor, DC Gear motor (spur gearbox and planetary gearbox), Stepper motors (stepping motor or step motor), Worm Geared motors, synchronous motor, brushless motor, servo motor, brake motor, sealed motor, hollow shaft motor, harmonic driver, linear stepper motor and other auxiliary electronic motor controls.

We have established an electrical consortium with small size electric motor manufacturers working as an exclusive exporters and world-wide sourcing agents of small electrical motors. These premium quality products are widely used in industrial automation, commercial and domestic automation.

Feel welcome to review all of our product range.

We are also proud to accept special design requirements from the customers.

Should you have questions about our product range, please contact our Sales Department.
