Shenzhen UPSEN Electronic Co., Ltd. >> No Breakssingle Phase 220V / 230V /240VAC Rack To19" 2u Rack Mount High Frequency UPS with External UPS Battery Pack and LCD Display for Green Solution 1K-10kVA
No Breakssingle Phase 220V / 230V /240VAC Rack To19" 2u Rack Mount High Frequency UPS with External UPS Battery Pack and LCD Display for Green Solution 1K-10kVA
| Price: |
US $ 1-100/Piece |
| Min Order: |
5/Piece |
| Pay Type: |
L/C,T/T,Western Union,Money Gram |
| Prod Model: |
Rack Tower Star Series RT 1K-10KVA |
| Transfer Time: |
Oms |
| Altitude: |
<1500m |
| Frequency Precision: |
50/60Hz |
| Communications: |
RS232 Serial Interface |
| Nominal Voltage: |
220/230/240VAC |
| Phase: |
Single Phase |
| Type: |
On-line |
| Protection: |
Overvoltage |
| Brand: |
Upsen or OEM |
Product Description
Product DescriptionHigh Frequency Online UPS Rack Tower Star Series RT 1K-10KVA(1Ph in/1Ph out)Key Features:
1:PWM Technology with IGBT
2:Rack Mount - Tower Convertible
3:Wide input voltage range, Zero transfer time
4:Input neutral and live wires reverse detection
5:Protection against all types of power problems
6:Humanization bypass output, can be adjustable
7:Smart RS232 communication with monitoring software
8:Diverse options of accessories, intelligent management
9:High frequency and double conversion online technology
10:Automatic startup function, Long-term type power design
11:With ECO (economic operation mode) can be highly efficient energy-saving, reduce user costs
Applications
Servers, Military,Medical Systems,Network sensitive electronic equipment,Electronic,Data processing systems,communication,water pump,microwave oven,Automation systems,air-condition,Commercial facility Intelligent equipment,fridge,Wind Power System etc.
Technical Specification
MODEL(RT Series) | RT1K | RT1KL | RT2K | RT2KL | RT3K | RT3KL | RT6KL | RT10KL |
| Input | Rated Capacity | 1KVA/800W | 2KVA/1600W | 3KVA/2400W | 6KVA/4800W | 10KVA/8000W |
| Voltage | 90 ± 5 ~290 ± 5Vac | 176 ~ 276Vac |
| Current | 6A(max) | 12A(max) | 16A(max) | 31A(max) | 60A(max) |
| Frequency | 40 ~ 60 Hz |
| Power factor | Conformity EN60555-2(≥0.95) | ≥0.95(MAX) |
| Output | Voltage | 220Vac ( 1 ± 2%) | 220Vac ( 1 ± 1%) |
| Current | 4.55A | 9.1A | 13.6A | 27.3A | 54A |
| Frequency | (50 ± 2)Hz | (50 ± 1)Hz |
| Power Factor | 0.8 lag |
| Waveform | Sine Wave |
| Waveform | Linear ≤ 7% when RCD 100% loading (Non-line) |
| Distortion | Linear ≤ 3% when RCD 100% loading (line) |
| Overload protection | 105%< <125% → 50s | 100%-125%, 1 minutes to |
| 125%< <150% → 25s | transfer to bypass; >150%, |
| >150% → 300s | 100ms to transfer to bypass |
| Transfer Time | Oms |
| Type of Battery | Sealed lead acid maintenance-free |
| External Battery Voltage | 3x7 Ah | 36Vdc | 6x7 Ah | 72Vdc | 8x7 Ah | 96Vdc | 192Vdc/240Vdc |
| Working | Operating | 0-40ºC |
| Environment | Temperatures(ºC) |
| | Relative | 0-90(%) |
| | Temperature(ºC) |
| | Altitude | <1500m |
| Communication | 9pin D trpe comector (RS232) |
| Size (WXDXH) mm | 482x450x88 | Standard Type (3U): 482x680x132.5 | 482x680x132.5 |
| Long Backup Type (2U): 482x450x88 |
| Weight (kg) | 14.5 | 8 | 22 | 9.8 | 26 | 9.8 | 20 | 25 |
Product and company Deatils
Shenzhen UPSEN Electronic Co., Ltd. Which is located in south of China, Shenzhen City, close to Pearl of the Orient HK, with beautiful environment and convenient transport.
We are a private high-tech enterprise integrating researching & development, production & operation and technical services as a whole, which is specialized in Electric, Electronic and Energy fields for a long time. Our main products are UPS Power, Inverter Power, Battery Power, Solar&Wind Power. We are dedicated to offer quality power and power solution for Data-center, Telecom, Bank, Hospital, Transportation, Industry, Army, Security, and civil & office area etc. Moreover, we have mastered the core technology of power products through our independent research, we are one of few domestic enterprises which can meet the customers' customized requirements, and provide professional power solutions.
We already past ISO9001 international quality system certification, and established a complete quality system ranging from material source, process, assembling to testing. All our products are with CE Certificate, which exported to more than 30 countries and areas, like Australia, Europe, Africa, North America, South America, the Middle East, central Asia, southeast Asia etc.
We will always offer excellent quality and products to customers. Hope to make Integrity and Double-Win business with you, and to be your professional power supplier and solve your any power problems. We are sure UPSEN can achieve more successes with our efforts and your support.
