Ntc Temperature Sensor

Name: Ntc Temperature Sensor
Brand: all-electronics-online.com
SKU: 800392055
Availability: InStock
Rating: 4.7 (82 reviews)

Price:	US $ 0.3-2.5/Piece
Min Order:	500/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	WD-TS001
B. Value Accuracy:	+/- 1%

Product Description

NTC Temperature Sensor for Pumbing and Mattress, Thermistor Temperature Probe, Temperature Probe:
High-Precision/accuracy, reliable NTC Thermistor linked with PVC wires, and been made to all different Shape by insulation/waterproof material, thus convenient to be mounted and temperature control in far distance,

Application range:
Wide used in Home Air-conditioner, Auto-Air conditioner, Refrigerator, ICE-Box, Water Heater, Water dispenser, Warm Air Blower, Dishwasher, Washing machine, dryer.. etc Temperature Control and Test.

Features:
*Nominal Resistance: R25(25ºC): 5~500KΩ (Usually: 50K, 100K, 200K, 500K)
*Resistance Precision:±1%, ±2%, ±3%
*BETA Value R25/50: 3300-4600K (Usually: 3950k, 3990K, 4100K, 4200K)
*BETA Value Accuracy: ±1%
*Operation Temperature range: -40ºC~+350ºC
*Max rated Power: 45mW
*Thermal Response Time: ≤ 7 S
*Temperature Coefficient of Resistance(TCR):2~5%/ºC
*Insulation Strength:DC500V/100MΩ

Characteristic:

Use nowest new Techinical, Quality is very stable, can used for a long time (annual resistance fluctuating ≤1‰)High Sensitivity, 2~5%/ºC TCRSmall size, simple mount and good water proofWide Temperature Operation Range, Nice stability and reliability.

APPROVAL

ROHS, CE, REACH,

NINGBO WEIDAN ELECTRONICS Co., Ltd. is located in Ningbo, the biggest modern port and the well-known export manufacturing base in China.

The company majors in producing following categories of products:

1. Network integration cabling products

Including Coaxial cable, Speaker cable, Alarm cable, Telephone cable, Network cable, Cat5e/CAT6/CAT6A/cat7 patchcord, Keystone jack, patch panel, wall faceplate, PDU, Wall faceplate; Fiber optic cable (LC/ST/SC/MTRJ, E2000), Adapter. Closure...

2. AV Cable: RCA, Seterio Audio, Scart, Guitar Cable, Musical instrument cable, Microphone cable, Snake Cable, HDMI & DVI Cable, Multimedia Swich box; ;

3. PC Cable and Mobility accessories: SVGA Cable, RS232, SATA I, II, III, , Printing cable, USB Cable, USB power lightening & Data charge cable, infinity band cable;

4. Power cord, Power Strip, Power cord reel;

5. Satellite and Antenna Communication products: Antenna cable, RF Cable, Amplifier, Splitter, Terminal Box;

6. WiFi Router, WiFi Bridge, IP Camera; ;

7. Appliance wiring Material. Fieldbus Cable, Drag Chain Cable, Robotics Cable, Servo, Feedback&Moto Cable, Sensor Cable and spiral cable.

WEIDAN ELECTRONICS is a younger company, but has already more than 15 years' professional experience accumulation, and developing very fast but steady, now, Our products being shipped as far as Europe, America, Asia, Australia, as well as South Africa and Middle East, 30 Countries and areas in the world. And has cooperated with and as the value supplier, provided the OEM service for many noted firms.

WEIDAN ELECTRONICS owns (or by cooperation) a number of modern production lines and scientific QC system, and equipped with full series professional Testing equipment, running according with ISO9000, CE, TUV, ETL, RoHS&REACH, . Moreover, we have strong R&D team, offer platform of technology supporting.

Under the principle of integrity, diligence and practicalness and by means of reinforcing management and effectiveness, WEIDAN ELECTRONICS insists that quality be the life of entreprises. With a strict budget and careful calculaton, the company purchases bulk raw materials in the form of a centralized bidding. If quality indicators of materials meet the criterion, costs are to be cut as much as possible. We boast of professional andzealous services for our clients, whose commodities have their value maintained and appreciated.

In hopes of having the WEIDAN products and services walk into hundrends of thousands of households all over the world, we'd like to communicate and cooperate with all those from all walks of life.
