Outdoor GYTA 48 Core Optical Fiber Cable

Name: Outdoor GYTA 48 Core Optical Fiber Cable
Brand: all-electronics-online.com
SKU: 752970015
Availability: InStock
Rating: 5 (149 reviews)

Price:	US $ 2/Meter
Trade Terms:	FOB,EXW
Min Order:	3000/Meter
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	GYTA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Outer Sheath Color:	Black
Outer Sheath Material:	PE
Metallic Strengthen Member:	Steel Wire
Filler:	Filling Compound
Single Armour Material:	Corrugated Aluminium Tape
Fiber Count:	2-288 Core
Brand Name Of Fiber:	Corning ,Yofc,Draka,Fujikura or as Your Requiremen
Waterblocking Material:	Water Blocking Tape or Filling Compound
Installation Style:	Duct, Aerial
Loose Tube Material:	PBT with Jerry
Application:	Communication
Type:	Multi-mode Fiber
Connection Structure:	SC
Certification:	ISO9001
Sheath Material:	PE

Product Description

GYTA with Aluminum Corrugated Tape 2-288 Core Optical Fiber Cable

Product Description

SHG outdoor Fiber optic cable GYTA, 2~144 fibers, central strength member (steel), jelly filled, fiber contained loose tube and filler stranded around the core, water blocking tape, aluminum polythene laminated applied around the inner core, filled with the filling compound to protect it from water ingress. Then, the cable is completed with a PE sheath.

Features:
1) Low dispersion and attenuation
2) Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental properties
3) Several protection ensure the cable watertight
4) Crush resistance
5) Operating Temperature: -40~+60c degree

Characteristics:

Fiber count	Cable dia. (mm)	Cable net Weight (Kg/km)	Min. Bending Radius (mm)			Min. Tensile Strength (N)			Min. Crush Pressure (N/100mm)
			Static state	Dynamic state	Short term		Long term	Short term		Long term
-30	11	106	110	220	1500		600	1000		300
32-36	11.6	126	120	240	1500		600	1000		300
38-60	12.3	135	130	260	1500		600	1000		300
62-72	13.1	168	140	280	1500		600	1000		300
74-84	13.9	184	140	280	1500		600	1000		300
86-96	14.7	202	150	300	1600		600	1000		300
98-108	15.5	220	160	320	1800		600	1000		300
110-120	16.3	239	170	340	1900		600	1000		300
122-132	17.1	259	180	360	2100		600	1000		300
134-144	17.9	280	180	360	2200		600	1000		300

Package: 2,3,4,5km/reel (wooden, wood, steel reel)

DONGGUAN TW-SCIE Co., Ltd. is a high-tech enterprise group in China devoted to communications undertakings with our own impoters and exporters rights. Since its founding, high quality products an strong co-operations have enabled the enterprise to stably and rapidly grow into a specialized communication

Manufacturer supplier and engineering service provider the most complete product line-up and specifications in the fiber and cable industry of China.

The enterprise is possessed of a passel of faithful, intelligent, conscientious talents. While bending ourselves to following with the worldwide advanced development and application, we build up cooperation ties with many scientific research academy.

The main products of our enterprise are:

Optical fiber, optical cable, Optical media converter, optical transceiver, optical coupler, optical modem, optical connector, optical distribution frame.

All of the products are widely used in telecom, electric power, railway and other related department, exporting France, India, Singapore, Malaysia.
