Popular Long Backup Power Office Equipment UPS

Popular Long Backup Power Office Equipment UPS
Price: US $ 300/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 10/Piece
Pay Type: L/C,T/T,Western Union
Prod Model: TX-T5000L
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
DC: 12V/24V/48V
Display: LED/LCD
Application: Computer / Alarm /Monitoring
Socket: as Required
Plug: as Required
Certificate: ISO,CE
Function: AVR,CPU
Battery: Built in/ Extended
Color: Normal Black
Feature: Compatible with Different Loads
Phase: Single Phase
Type: Line Interactive
Protection: Overvoltage

Product Description

Description: :
1. Accurate pure sine wave output; Strongly compatible with different loads;
2. Wide range of input and accurate output;
3. Smart RS232 communication port;
4. Perfect protection for overload, short circuit, over-voltage, low-voltage and over-heating etc;
5. LED Indicator;
6. UPS restart automatically when the main power recovers (optional);
7. Built-in super smart charger, shorten 50% of charging time;
8. Charging ability at low input voltage, 2 times more powerful than other.


Applications:
- High quality and availability of energy adapted to suit specific critical needs
- Covering a vast range of applications. Applied to key devices.
- Communication system.
- Computer network system.
- Some devices need harsh electric power environment.
Specifications:

Note: "L" means long back up model &"M" means standard model with inbuilt battery...
MODEL   TX-T500M/L TX-T1000M/L TX-T2000M/L TX-T3000M/L TX-T5000M/L
CAPACITY W 500VA(350W) 1KVA(700W) 2KVA(1400W) 3KVA(2100W) 5KVA/3500W
INPUT Phase Single
Voltage 100/110/127/220/230(+25%,-25%)
Frequency 60/50+/-10%
OUTPUT Phase Single
Voltage range(VAC) 100/110/127/220/230+/-5%
Frequency Commercial power supply shared frequency with the commercial inversion state:60/50+/-0.5
Waveform Sine wave
Power Factor P.F. 0.7 0.7 0.7
BATTERY Battery Type & Number 12V/7AH x 1pcs 12V/7AHX2PCS 12V/17AH x 2pcs 12v/17AHx2pcs  12v/17AHx4pcs
DC Voltage 12VDC/24VDC 24VDC 48VDC
Back up Time Standard model: (halfload)>/=8min
Recharge current Long back up model: 15A max, standard model: 3A max
TRANSFER TIME Typical Typical: 5ms (Including detection time)
Display LCD/LED Optional
PROTECTION Full Protection Discharge, overcharge, and overload protection
PHYSICAL Dimension, DXWXH (mm) 375*130*190 452*192*338 452*192*338
Out packing Size, DXWXH (mm) 495*490*320(2pcs/ctn) 584*335*495(1pcs/ctn) 584*335*495(1pcs/ctn)
Net Weight (kgs) 12/7(L) 23/15.6(L) 27/23.7(L) 33.7
ENVIRONMENT Operating Environment 0~40 Degrees Centigrade, 0~90% relative humidity (non-condensing)
Noise Level Less than 40dB
INTERFACE Smart RS-232 Support Windows family, Linux, Compaq True64,
USB Option N / A
