Security Alarm Wireless Gas Leak Sensor

Name: Security Alarm Wireless Gas Leak Sensor
Brand: all-electronics-online.com
SKU: 740253535
Availability: InStock
Rating: 4.4 (143 reviews)

Price:	US $ 6-6.5/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	WL-938W
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Response Time:	Below 20 Seconds
Certificated:	RoHS/CE Certificated
Working Voltage:	220VAC
Output:	Nc\No or Level Output
Work Temperature:	>-10<+55
Installation Mode:	Wall Mounted
Application:	Home, Industry
Usage:	Gas
Output Signal Type:	Wireless Repeater
Type:	Sensor

Product Description

Features:

Alarm indicator: Green led flash
Manual test; Auto reset
Detects natural gas, coal gas, LPG
Highly stable semiconductor gas sensor
SMT manufacture technology, high stability
Adopts check malfunction
High capacity relay (0.3A/250V)
RF signal: 433MHz (wireless type)
Execute criterion: GB15322.2-2003
ABS plastic material
Can work with solenoid valve, the fan (WL-938WL/938DL type)

Technical Specification

Model	WL-938W / 938WL	WL-938D / 938DL
Model type	Wireless/ Wireless Linkage type gas detector	Independent /Linkage type Independent gas detector
Power supply	AC 220V	90V-240V AC
Alarm concentration	10%±5%LEL (5000PPM)
Transmitting distance	≤300m (in open area)	≤300m (in open area)
Installation height	0.3 to 1.0m, from ceiling/floor	0.3 to 1.0m, from ceiling/floor
Sound level	≤85dB/m	≤85dB/m
Transmitting frequency	433MHz	/
Detecting area	20m2
Programmer code	1527/2264	/
Standby current	≤70mA	≤70mA
Alarm current	≤160mA	≤160mA
Operating temperature	-10ºC~ +55ºC	-10ºC~ +55ºC
Relative humidity	≤95% RH (non-condensing)	≤95% RH (non-condensing)
Unit size	1306838mm
