Slmne Moulded Case Circuit Breaker

Name: Slmne Moulded Case Circuit Breaker
Brand: all-electronics-online.com
SKU: 734636785
Availability: InStock
Rating: 5 (39 reviews)

Price:	US $ 10-20/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	100/Piece
Pay Type:	L/C,T/T,D/P,Money Gram,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	SLMNE Moulded Case Circuit Breaker
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
MCCB:	Moulded Case Circuit Breaker
Structure:	MCCB
Breaking Capacity:	Low Voltage Circuit Breakers
Poles Number:	3
Certification:	CCC
Operation:	Electric Type
Installation:	Fixed
Arc-extinguishing Medium:	Air
Speed:	Normal Type Circuit Breaker

Product Description

Application

SLMNE moulded case circuit breaker is one of the most advanced type breakers in the world, which adopts international advanced design and manufacture technology. They are suitable for short circuit and overload protection for circuit of AC 690V 50/60Hz, rated current from 12.5A to 160A. Its rated insulation voltage is AC 690V. It can make and bresk the non-frequent circuit in the normal conditions. It takes protect effect when mouse cage motors non-frequent start, breaking off
Working and protecting overload, short circuit and lacking voltage. It complies with IEC60947-2.

Specicarions

Type			SLMNE 60E	SLMNE 100F	SLMNE 100H	SLMNE 250
Number of poles			3	3	3	3
Rated current In(A)			15,20,25,30, 40,50,60	15,20,25,30,40, 50,60,75,80,100	15,20,25,30,40,50, 60,75,80,100	125,160,225, 250
Rated operating voltage Ue(V) AC50/60Hz			500	500	500	500
Rated Insulation voltage Ui(V)			500	500	500	500
Rated(kV) Uimp			6	6	6	6
Breaking capacity(kA ms) IEC60947-2	Icu AC	220/240V	10	25	50	85
		380V	7.5	10	30	18
		400V	7.5	7.5	20	15
	Ics%Icu	220/240V	25%	25%	25%	50%
		380V	25%	25%	25%	50%
		400V	25%	25%	25%	50%
Breaking capacity(kA) (NEMA-ABI) (HIC)	AC	240V	-	-	25	25
Breaking capacity(kA) (NEMA-ABI) (HIC)	AC	480V	-	-	10	10
Mechanical life			8.500	8.500	8.500	8.500
Electrical life			4.000	4.000	4.000	4.000
Overload current protection(A)	Hot protection		Fixed	Fixed	Fixed	Fixed
Overload current protection(A)	Magnetism protection		Fixed	Fixed	Fixed	Fixed
Dimensions(mm) LxHxD			75x130x60	75x130x60	75x130x60	105x165x65

Wenzhou Suoli Electric Co, . Ltd. (will change the namer to Wenzhou Manjia Electric Co., Ltd. ) is a manufacturer specialized in low-voltage electrical appliance, gathering research, manufacture, distribution and service as a whole. We mainly produce switch cabinet, JXF, distribution box, lighting box, plastic water-proof and dust-proof junction box, seal box, MCBs and so on.

Our company is established in 1995, located in Yueqing economic development zone with an area of 7800 square meters which is next to national highway 104, the transportation is very convenient.

Relying on powerful technology strength, advanced testing equipment, exquisite technical and modernized management mode, based on the principle that people oriented, we have 200 workers and 20 engineers. We import numerical control bending machine, cutting machine, punch, injection molding machine and such top-ranking facilities. Our products have passed certification of SON, CE and ISO9001.

The satisfaction of customers is our wishes and responsibility. In order to offer best services, we require all the staff to strengthen the notion of customer first. Besides, we also have established the center of after-sale services.

The company always keeps in touch in with clients and communicates with potential clients. Suoli always has been keeping the idea of the human being as base and considers honesty as the foundation, peace as the most valuable thing, and puts credibility in the first place.

Together with you, Souli is willing to create a better future.
