Stainless Steel Probe Housing Refrigerator Ntc Thermistor Sensor
| Price: |
US $ 0.2-8.5/Piece |
| Min Order: |
1000/Piece |
| Pay Type: |
L/C,T/T |
| Prod Model: |
WD-TS004 |
| B. Value Accuracy: |
+/- 1% |
| B. Value: |
3920k, 3950k |
| Resistance: |
2k/2.25/5.06 KΩ |
| Cable: |
Copper Cable |
| Operating Temperature: |
-40c-80c |
Product Description
Stainless Steel Probe Housing Refrigerator NTC Thermistor Sensor Probe---This Stainless Steel Thermistor Sensor designed for Refrigerators, is made with high Prcision, Reliable NTC Thermistor Connected to qualified Wire, WHich is Wrapped with insulated, Heat conductive and Water resistant Materials into desired Shapes, so as to facilitate long-distance temperature Measurement and Control and installation.
| Resistance Value @25ºC | 2KΩ,2.252KΩ, 2.7KΩ, 5KΩ, 10KΩ |
| Tolerance on R25-Value | ±1%, ±2% |
| B Value | 3899K, 3920K, 3950K, 3984K |
| Tolerance on B25/85-Value | ±0.5% |
| Operating Temperature Range at Zero Power | -50ºC ~ + 80ºC |
| Min.Dielectricc withstanding Voltage(immersed in water) | 3750 VAC |
| Maximum Power Dissipation @ 25 ºC | 150mW |
Note;
1. NTC Thermistor Chip with Expoxy Coating and Special Potting Resins
2. Stainless Steel Cap
FEATURES; it's Key Component for Temperature Sensing and Electronic Control
Sensor Design following principal+ Supplementary Insulation for the Sensor head
High adhesive Strength between PVC Wire and encapsulating Lacquer.
Specifically developed design allows for a very good water, moisture and ice resistance: 6000Hr immersion under Voltage.
Suitable for evaporater temperature measurement, Very high Number of thermal Cyles resistant: 100 000 Cycles
The Cable jacket are suitable for back-panel polyurethane foaming process (Max. 100ºC, 5Min)
The Sensor are also available with Single insulated cables. and with PVC-Free Cable.
Applications: Temperature Measurement, Sensing and control:
*White Goods
*Refrigerators
*Freezers, deep-freezers
*Ice Cube Makers
*Counter drink Coolers
*Backbar and Catering Coolers
*Display fridges
*Wine Coolers.
