SVC-E High Accuracy Automatic AC Voltage Stabilizer

Name: SVC-E High Accuracy Automatic AC Voltage Stabilizer
Brand: all-electronics-online.com
SKU: 690327155
Availability: InStock
Rating: 4.3 (53 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	SVC-E
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Current Type:	AC
Phase:	Single Phase
Usage:	SVC

Product Description

Specifications
1. Certification: CCC CE
2. Warranty: 1 year
3. Spec.: SVC-E0.5~30kVA
4. We can offer the most lowest price.

SVC-E(Digital display type) High Accuracy full automatic AC voltage stabilizer
General
SVC-E (Digital display type) series single-phase voltage stabilizer adopts digital display technology, it can display the delay time, output voltage and protection state automatically and has advantages of time-delay protection, over-voltage and under-voltage protection, automatic alarming, etc. (Note: Product of 2kVA and above 2kVA only has protection time-delay protection, over-voltage and under-voltage, and also has function of putting through commercial power directly)
Application
For office equipment, test equipment, medical equipment, industrial equipment, household appliance, lighting system, commucation system, etc.
Performance:
Input voltage: Single-phase 140V-250V
Output voltage: (0.5kVA-5kVA: Single-phase 220V and 110V) (8kVA-30kVA: Single-phase 220V)
Voltage stabilizing precision: 220V± 3% and 110V± 6%
Frequency: 50Hz/60Hz
Adjusting time: <1s(when input voltage changes for 10%)
Efficiency: >90%
Over-voltage protection: 246± 4V
Delay time: Long 5min± 2min, short 5s± 2s
Ambient temperature: -10oC - +40oC
Relative humidity: <95%
Waveform distortion: No additional waveform distortion
Load power factor: 0.8
Dielectric strength: 1500V/min
Insulation resistance: >5MΩ
Common Specifications: 0.5kVA ~ 30kVA, if you have any requirments special specifications pls contact with us.
