| Prod Model: |
YJLV, YJLV22, YJLV32, YJLV42 |
| Delivery Time: |
Within 10-15 Workdays |
| Delivery Length: |
Accord with The Request |
| Factory Area: |
100000m2 |
| Experience: |
20 Years |
| Application: |
Power Station |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
DC & AC |
| Insulation Material: |
XLPE |
| Certification: |
RoHS |
| Wire Core Material: |
Alumininum |
| Model: |
Yjlv, Yjlv22, Yjlv32, Yjlv42 |
| Brand: |
Huatong |
Product Description
Three core 600/1000V cables with stranded copper conductors
1.Application
These power and control cables are used for electricity supply in low voltage installation system. They are well adapted to underground use in industrial applications where chemical and mechanical protections are needed (refinery areas, chemical plant...).
2.Stranded: BS 6460, IEC 60228.
3.Colour Code: 1 Core : Brown
2 Cores: Brown or Blue
3 Cores: Brown, Black, Grey
4 Cores: Blue, Brown, Black, Grey
5 Cores: Green-yellow, Blue, Brown, Black, Grey,Above
6 Cores: White Cores with black numbers
4. Filler(optional) PVC or Polypropylene yarn
Binder Tape(optional) Polyester (Mylar) tape
Inner Sheath/ Bedding PVC (Polyvinyl Chloride)
Armour Single Core: AWA (Aluminum WireArmour)
Multi Core: SWA (Steel Wire or Tape Armour)
Outer Sheath PVC(Polyvinyl Chloride), type TM1
5.Technical Information of three core 600/1000V cables with stranded Aluminum conductors
Voltage rating 600/1000V
Temperature rating -20°C to +60°C
Bending radius Single core: 10 x overall diameter
Multicores: 8 x overall diameter
Flame retardant IEC60332 part 1, BS4066 part 1
6.Other product :
1) PVC Insulated Power Cable
2)1~35kV XLPE Insulated Power Cable
3) Aerial Insulated Cable
4)Aerial Bundle Cable ( abc cable )
5)Control Cable
6)Bare Overhead Conductor (AAC/AAAC/ACSR)
7)Non-sheathed PVC Insulated Cable (The highest rated voltage is 450/750V)
8) Sheathed PVC Insulated Cable (The highest rated voltage is 450/750V)
9)XLPE Insulated Cable for Coal Mine Application
10)Underground Wire for Agricultural Application
we can manufacture one to five cores all kinds of VV cable.
7.
China Type |
Description |
Application |
Cu |
Al |
YJV |
YJLV |
XLPE insulation PVC sheath power cable (Cu/XLPE/PVC) |
To be laid indoors, in tunnel, cable furrow or pipe, the cable couldn't bear mechanical force outside |
YJY |
YJLY |
XLPE insulation PE sheath power cable (Cu/XLPE/PE) |
YJV22 |
YJLV22 |
XLPE insulation, steel tape armor, PVC sheath power cable
(Cu/XLPE/PVC/STA/PVC) |
To be laid underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force. |
YJV23 |
YJLV23 |
XLPE insulation, steel tape armor, PE sheath power cable
(Cu/XLPE/PVC/STA/PE) |
YJV62 |
YJLV62 |
XLPE insulation, no magnetism steel tape armor, PE sheath power cable |
YJV32 |
YJLV32 |
XLPE insulation, thin steel-wire armor, PVC sheath power cable
(Cu/XLPE/PVC/SWA/PVC) |
Be applicable to the well, water inside and fall in the bad soil, the cable cans bear the equal dint outside the machine with pull the dint
. |
YJV72 |
YJLV72 |
XLPE insulation, have no the magnetism thick steel-wire armor, PVC sheath power cable |
YJV42 |
YJLV42 |
XLPE insulation, thick steel-wire armor, PVC sheath power cable |
Be applicable to the well, underwater with the bottom of sea, the cable cans bear the bigger pressure with lead to pull the dint. |
