Tsw8 Intelligent Air Circuit Breaker

Name: Tsw8 Intelligent Air Circuit Breaker
Brand: all-electronics-online.com
SKU: 753935775
Availability: InStock
Rating: 4.9 (146 reviews)

Price:	US $ 714-1124/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	TSW8
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Western Europe
Number Of Poles:	3, 4p
Rated Current (a):	630~6300
Rated Voltage:	AC400V, 690V
Frame Rated Current Inm (a):	2000-630
Electrical Life:	23-32ms
Mechanical Life:	Maintenance-Free 2500, Maintenance 10000
Mounting Mode:	Fixed Type or Withdrawable Type
Intelligent Controller:	Standard Type (M) Telecommunication Type (H)
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Electric Type
Speed:	High-Speed Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Fixed
Structure:	ACB
Certification:	CCC
Poles Number:	1, 2, 3, 4

Product Description

Specification

Type			TSW8-2000	TSW8-3200	TSW8-4000	TSW8-6300
Frame Rated Current Inm (A)			2000	3200	4000	6300
Number of Poles			3, 4	3, 4	3, 4	3, 4
Rated Current (A)			630, 800, 1000, 1250, 1600, 2000	2000, 2500, 2900, 3200	3200, 3600, 4000	4000, 5000, 6300
Icu (kA)		400V	80	100	100	120
		690V	50	65	65	80
Ics=Icw (kA)		400V	50	80	80	100
		690V	40	50	50	65
Rated Current at N-pole ln (A)			50% ln, 100%ln
Inherent Making & Breaking Time			23-32ms
Operational Performance	Electrical Life		500
	Mechanical Life		Maintenance-free 2500 Maintenance 10000
Mounting Mode			Fixed type or withdrawable type
Arcing Distance (mm)			0
Intelligent Controller			Standard type (M) telecommunication type (H)
