Fiber Optic Adapter Simplex SM

Features:
Complies With IEC 61754-4;
Flammability: UL94 V-0 Grade;
RoHS directive compliance
Sleeve material:
Zirconia Split Sleeve for SM adapter
Phosphorous bronze Split Sleeve for MM adapter;

Application:
Fiber Optic Transmission Network
Cable TV network
Optical Fiber Lan
Optical fiber testing instrument
ODF,rack-mounted and wall-mounted optical fiber wiring unit

Specifications:

Parameters	Singlemode			Multimode
Parameters	PC	UPC	APC	PC
Insertion Loss(dB)	≤0.3	≤0.2	≤0.3	≤0.2
Return Loss(dB)	≥45	≥50	≥60	≥30
Interchange ability(dB)	≤0.2
Repeatability(dB)	≤0.2
Durability	>1000matings
Operating Temp.(ºC)	-40~75
Storage Temp. (ºC)	-40~75

Order Information:

Type	Type	Fiber type	Material	Flange	type	Sleeve	Application
SC LC FC ST	SX=Simplex DX=Duplex QU=Quad	S=Single Mode M=Multi-mode	P=Plastic PBT M=Metal	L=Flanged S=Flangeless F=Flangeless with shutter	B=Blue G=Green E=Beige A=Aqua M=Metal Ni- Plated	Z=Zirconia Split M=Metal Split	P=PC A=APC

----------------------------------------------------FAQ---------------------------------------------------

Q1. Can I have a sample order for this product? What' MOQ of it?
A: Yes welcome send sample order for test. MOQ is 1 piece.

Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks.

Q3: What' s the payment term
A: We usually use TT(Telegram Transfer) in advance, Western Union. Other payment method is negotiable.

Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5: What' s the freight of it?
A: It depends on the order quantity. We have some reliable ship forwarders. We will offer cost effective method for you.

Q6: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty according to different products.

Q7: What action will you take if there are some product problems?
A: If there are defective ones in the batch of products, we will offer spare ones for.

Prod Model:	Fiber Optic Adapter Simplex SM
Connection Structure:	LC
Certification:	RoHS, ISO9001, UL
Structure:	LC
Number Of Cores:	Single-Core
Application:	Communication, Medicine
