250VAC Metal Medical Foot Switch

1.China Medical Foot Switch:
Model No.:XF-502
15A 250VAC
OEM accept.

2.Adopt metalshell, hard and strong in volume, stand wear and tear.
Widely used in various of industrial machinery, just like industrial automation installment, transport, stamping, medical treatment, testing etc.


Contact resistance	25mΩ(Initial value)
Insulation resistance	100mΩ(above)DC500V
Withstand voltage	>=2000VAC
Mechanical life	1,000,000 above
Electrical life	100,000 above
Operating temperature	-20~+70ºC
Operating humidity	<=85%

3.Specification

Item	Specification
Model Name	FS-502
Rating	15A 250VAC
Contact	1C
Material of Rind	Aluminum
Insulation resistance	≥100MΩ
Contact resistance	≤25mΩ
Withstand voltage	2000VAC
Electrical life	≥100,000
Protection degree	IP65
Temperature	-25-75°C
Humidity	<85%

4.Why choose our switches

1) We can provide you with different types of micro switches for your selection.

2) We can offer good quality electric life 500, 000-1, 000, 000times.

3) Various operating force, height and color for one switch for your choice.

4) Safety, on-time delivery, excellent quality with competitive price.

5) ODM&OEM professional design.

5.Customer's questions

Q1:How about the delivery time?
Answer:It's depends on the quantity, for example, 10000PCS need to OEM,
delivery time is 3-7 days.

Q2:What quality you can offer to us?
Answer:We now can do 1/2 years warranty, during the warranty time we can exchange all defective products from customers for free.

Q3:Can you give me samples to test?
Answer:Yes

Q4:What's you MOQ?
Answer:MOQ 100PCS, mixed order acceptable, welcome trial order.

6.More information of our products, please do feel free to contact us.
Reply will be available within 24 hours. Thanks!
