EV Unshileded Insulated Silicone Cable Dw25

Name: EV Unshileded Insulated Silicone Cable Dw25
Brand: all-electronics-online.com
SKU: 784574455
Availability: InStock
Rating: 5 (103 reviews)

Price:	US $ 3.26-6.78/Meter
Trade Terms:	FOB,EXW
Min Order:	3000/Meter
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

EV unshileded insulated silicone cable dw25
Nominal voltage: 1000V
Temperature range: -40º C-+200º C
O. D. Tolerance: ± 0.1mm
Conductor:Annealed bare copper wire
Insulator: Silicone rubber.
Color:orange
The packing: 100/coils

sectional area (MM2)	conductor			insulation		packing (M)
sectional area (MM2)	single Cooper wireDIA.±0.08mm	number of branches±10‰	Max resistance in 20ºC(mΩ/m)	Insulation thickness(mm)/ Min.thickness (mm)	Insulation O.D.( mm) /±tolerance mm	packing (M)
1.5	0.2	48	12.7	0.60/0.48	2.93±0.20	100
2.5	0.2	84	7.6	0.70/0.56	3.70±0.20	100
3.0	0.2	98	6.15	0.70/0.56	3.90±0.25	100
4.0	0.2	133	4.71	0.80/0.64	4.50±0.25	100
5.0	0.2	161	3.94	0.80/0.64	4.80±0.25	100
6.0	0.2	196	3.14	0.80/0.64	5.10±0.30	100
10	0.2	322	1.82	1.00/0.80	6.50±0.30	100
16	0.2	513	1.16	1.00/0.80	8.10±0.35	100
25	0.2	798	0.743	1.30/1.04	10.2±0.40	100
35	0.2	1121	0.527	1.30/1.04	11.5±0.40	100
50	0.2	1596	0.368	1.50/1.20	13.50±0.50	100
70	0.2	2318	0.259	1.50/1.20	15.30±0.50	100
95	0.2	3059	0.196	1.60/1.28	17.40±0.50	100
120	0.2	3857	0.153	1.60/1.28	19.20±0.50	100

Printing:EV **mm ATTENTION HIGH VOLTAGE MAX 1000V AC DEWEI WIRE

Prod Model:	dw25
Markets:	North America,South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
EV Unshileded Silicone Cable:	Annealed Bare Copper Wire
Type:	Insulated
Conductor Type:	Stranded
Application:	Underground
Insulation Material:	Silicone Rubber
Certification:	VDE
Conductor Material:	Annealed Bare Copper Wire
Sheath Material:	Silicone Rubber

DONGGUAN DEWEI WIRE Co., Ltd, established in 2004, specializes in manufacturing various kinds of silicone sleeve and electrical cable: Silicone rubber wire, FEP wire, PFA wire, PTFE wire, ETFE wire, heating wire, braided wire, power cable, twin flat cable, coaxical cable, high temperature cable and high voltage cable which can meet the requirements of UL, VDE, CCC.

Besides, we set up a wire processing workshop to provide customers with well processed wire group and wire harness of the batteries, the brushes, electric adjustment, steering gear, all kinds of JST, AMP connector, T-type plugs, banana plugs etc,

We set up and implement quality management system strictly according to international standard ISO9000, and had been awarded the certification of AMT ISO 9001: 2008 in 2009.

Our philosophy is quality-oriented, continuous innovative, reputation first and to treat our clients sincerely. In the meantime we persist in providing our customers with competitive high-quality products, creating a belief that quality decides the survival of the company.

Welcome to visit and give advice, let' S work together and create brilliant future.
