High Gain GPS Lte WiFi Antenna, Waterproof GPS 4G WiFi Antenna, GPS GSM 3G 4G Lte WiFi Screw Antenna, Outdoor GPS Lte WiFi Car Antenna

Name: High Gain GPS Lte WiFi Antenna, Waterproof GPS 4G WiFi Antenna, GPS GSM 3G 4G Lte WiFi Screw Antenna, Outdoor GPS Lte WiFi Car Antenna
Brand: all-electronics-online.com
SKU: 730549252
Availability: InStock
Rating: 4.7 (67 reviews)

Price:	US $ 12-13/Piece
Min Order:	10/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

GPS/4G LTE/WIFI Combo Antenna Specifications:

Part Number: WK-GPS/LTE/WIFI007
Size	25×25×4mm
Center Frequency	1575.42MHz±3 MHz
V.S.W.R	1.5:1
Band Width	±5 MHz
Attenuation	fo±100MHz>30dB
Impedance	50 ohm
Peak Gain	>3dBic, Based on 7×7cm ground plane
Gain Coverage	>-4dBic at -90°<0<+90°(over 75% Volume)
Polarization	Right-handed Circular(RHCP)
LNA specifications
LNA Gain (Without cable)	28dB Typical
Noise Figure	1.5dB
V.S.W.R	<1.65
DC Voltage	2.7V-5.0V±0.5V
DC current	15mA Max(5V DC)
4G LTE specifications
Frequency Range	698-960/1710-2700MHz
V.S.W.R	2.0:1
Gain	3.5dBi
Polarization	Vertical
Radiation	Omni directional
Max Input power(W)	50
Impedance	50 ohm
WIFI specifications
Frequency Range	2350-2500MHZ
V.S.W.R	1.5:1
Band Width	±100 MHz
Gain	2.15dBi
Polarization	Vertical
Radiation	Omni directional
Max Input power(W)	50
Impedance	50 ohm
Mechanical Specifications
Weight	<300g
Cable	GPS: 4m RG174, RG316, LMR100 or other LTE: 4m RG174, RG316, LMR100 or other WIFI: 4m RG174, RG316, LMR100 or other
Connector	GPS: SMA male straight, SMB, FME, FAKRA or other LTE: SMA male straight, SMB, FME, FAKRA or other WIFI: RP-SMA male straight, SMB, FME, FAKRA or other
Mounting	Screw
Housing	Ø80x14mm, Black ABS
Environmental Specification
Working Temp	-40ºC~+85ºC
Vibration	Sine sweep 1g(0-p), 10~50~10Hz each axis
Humidity	95%~100%RH
Weatherproof	100%Waterproof
MTBF=1×10-6/pc.hr	40ºC±5ºC, DC=3.0V±0.5V, 2000pcs For 480h

Prod Model:	WK-GPS/LTE/WIFI007
Antenna Type:	Combo Antenna
Usage:	Broadcasting Antenna
Operating Wavelength:	Microwave
Directionality:	Omnidirectional Antenna
VSWR:	<1.5
