High Tg PCB Circuit Board Differential Impedance 90 Ohm
| Price: |
US $ 0.9/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-698-V6.98 |
| High Tg PCB Circuit Board Differential I: |
0.20mm |
| Pth Cu Thickness: |
≥20 µm |
| Surface Cu Thickness: |
35 µm |
| Coverlay Colour: |
Black |
| Thickness Of Coverlay: |
25 µm |
| Color Of Silkscreen: |
White |
| Peeling Test Of Coverlay: |
No Peelable |
| Surface Finish: |
Immersion Gold |
| RoHS Required: |
Yes |
| Test: |
100% Electrical Test |
| Structure: |
Double-Sided FPC |
| Material: |
Polyimide |
| Combination Mode: |
Adhesive Flexible Plate |
| Conductive Adhesive: |
Conductive Silver Paste |
| Application: |
Keypad Antenna |
| Insulation Materials: |
Polyimide |
| Brand: |
Bicheng |
Product Description
Company ProfileAn Experienced PCB Provider since 2003
Established in Shenzhen in 2003, Bicheng Enterprise Limited is an experienced PCB supplier.
We are widely-recognized and have a strong network in the PCB industry. As an ISO 9001-2008
-, ISO 14001-2004-, ISO/TS 16949:2009- and UL-compliant, we offer different types of PCB from
fiberglass, high frequency, metal core and ceramic. Our 16,000-square-meter factory can produce
30,000 square meters with 8,000 types of PCB per month.
Various PCBs are Available
Our extensive product line includes double-sided PCBs, multi-layer PCBs (up to 32 layers), FR-4
PCBs (Tg130 - Tg170), high frequency PCBs (RO4350B, RO4003C), aluminum PCBs (1W/MK,
2W/MK, 3W/MK), flexible PCBs and HDI PCB boards.
Having Multiple PCB Technology to Meet the Market Demands
Our plants use state-of-the-art equipment during our production and testing phase in order
to ensure quality and to meet the market demands. These include heavy copper testers,
impedance control testers, automatic target drill machines, PCB cleaning machines and
more.
Offering New Customer Promotion
For new customers, we offer SMT stencil foil, PCB panelization and prototype testing free of
charge.
Our other advantages include:- Our engineering design prevents problems from occurring during pre-production
- We can meet your PCB needs from prototype to mass volume production
- Eligible products rate of first production: >95%
- Delivery on time: >98%, door to door shipment service
- Customer complaint rate: <1%
Our advantages help you maximize your profit by saving time and cost. Contact us now.
Printed Circuit Board
High Frequency PCB
Aluminum PCB
Flexible PCB
Technology information
Bicheng Flexible Printed Circuit Capability| No. | Specifications | Capabilities |
| 1 | Board Type | Single layer, Doulbe layer,
Multilayer, Rigid-Flex |
| 2 | Base Material | PI, PET |
| 3 | Copper Weight | 0.5oz, 1oz, 2oz |
| 4 | LED Maximum Size | 250 x 5000mm |
| 5 | General Maximum Size | 250 x 2000mm |
| 6 | Board Thickness | 0.03mm-3.0mm |
| 7 | Thickness Tolerance | ±0.03mm |
| 8 | Mininum Drill Hole | 0.05mm |
| 9 | Maximum Drill Hole | 6.5mm |
| 10 | Tolerance of Drill Hole | ±0.025mm |
| 11 | Thickness of Hole Wall | >= 8 um |
| 12 | Minimum Track/Gap of Single
Layer Board | 0.025/0.03mm |
| 13 | Minimum Track/Gap of Double Layer
and Multilayer Board | 0.03/0.040mm |
| 14 | Etching Tolerance | ±0.02mm |
| 15 | Minimum Width of Silk Legend | >= 0.125mm |
| 16 | Minimum Heigh of Silk Legend | >=0.75mm |
| 17 | Distance from Legend to Pad | >=0.15mm |
| 18 | Distance from Opening Solder Mask
of Drill Coverlay to Track | >=0.03mm |
| 19 | Distance from Opening Solder Mask
of Punching Coverlay to Track | >=0.03mm |
| 20 | Thickness of Immersion Nickel | 100-300u" |
| 21 | Thickness of Immersion Gold | 1-3u" |
| 22 | Thicnkess of Immersion Tin | 150-400u" |
| 23 | Minimum Electrical Testing Pad | 0.2mm |
| 24 | Minimum Tolerance of Outline
(Normal Steel Mould Punch) | ±0.1mm |
| 25 | Minimum Tolerance of Outline
(Precision Steel Mould Punch) | ±0.05mm |
| 26 | Mininum Radius of Bevel Angle (Outline) | 0.2mm |
| 27 | Stiffner Material | PI, FR-4, 3M Adhesive, PET,
Steel Sheet |
| 28 | RoHs | Yes |
| 29 | Solder Mask Colour | Yellow, White, Black, Green |
