Infrared Sensor SF6 Sulfur Hexafluoride Leak Alarm

Name: Infrared Sensor SF6 Sulfur Hexafluoride Leak Alarm
Brand: all-electronics-online.com
SKU: 837760255
Availability: InStock
Rating: 4.8 (101 reviews)

Price:	US $ 100-250/Piece
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

SF6 Infrared Gas Sensor IR Module FAD
G series infrared SF6 gas sensors uses non-dispersive infrared (NDIR) detection technology, with advantages of long life, low cost, intelligence, micro etc. Sensor is easy to use, with a complete gas detection, serial communication function, widely used in ventilation systems, industrial control, environmental monitoring and other industries.

SF6 Infrared Gas Sensor Features

Detecting gas	SF6
Operating voltage	12-24VDC
Operating current	Average 80mA (10-120mA )
Output	RS485 Net 4-20mA Current 0.4-2V Voltage
Response time T90	< 30s
	15s(500ml/min)
Recover time	25
Measuring flow rate	300-500 ml/min(pump)
Repeatability	≤±2% FS
Linearity error	≤±1% FS
Zero point temperature drift	≤±0.1% FS/°C
Span temperature drift	≤±0.1% FS/°C
Temperature	-20°C -50°C
Humidity	0-95%RH
Lifetime	10 years
Dimension	65mm35mm20mm

Selection

Gas	G-40	GP-40	Range	Precision	Resolution	Power Supply	Output
SF6	SF6/G-40-1000P	SF6/GP-40-1000P	0-1000 ppm	±3%FS	1 ppm	12-24VDC	RS485/4-20mA/0.4-2V
	SF6/G-40-2000P	SF6/GP-40-2000P	0-2000 ppm	±3%FS	1 ppm	12-24VDC	RS485/4-20mA/0.4-2V
	SF6/G-40-3000P	SF6/GP-40-3000P	0-3000 ppm	±3%FS	1 ppm	12-24VDC	RS485/4-20mA/0.4-2V

Application
Online monitoring
Site construction protection
SF6 leak alarm in electric power environment

Prod Model:	SF6-G(GP)-range
Output:	RS485/4-20mA/0.4-2V
Precision:	5%Fs
After Sale Service:	Yes
Customize:	Yes
Certification:	Other

Company introduction

Advanced Sensors Application Technology Co., Ltd. Was established on 2003. We are passionate about delivering high quality gas sensor products to our customers. Focus on customized manufacturing, we supply widely to many key industries through our diverse and state-of-art facilities. We have a technician team to support in material designs and testing to international standards meeting customers' requirements.

Products are widely used in petroleum, petrochemical, metallurgy, chemical, electricity, telecom, gas, mining, pharmacy, municipal wastewater treatment, indoor environment, atmospheric environmental protection, transit equipment, transportation facilities, tunnel safety and underground parking.
