Metal RJ45 8p8c Adapter/ 12V Network Connector

Name: Metal RJ45 8p8c Adapter/ 12V Network Connector
Brand: all-electronics-online.com
SKU: 777032355
Availability: InStock
Rating: 4.5 (126 reviews)

Price:	US $ 4.5/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

RJ45 series electrical connectors IP67
LP-24 Series connectors ,containing RJ45,USB,power,fiber optics and other models with hole size 24MM to meet different needs of industry and we use nickel-plated and Zinc alloy to guarantee quality and apply with international environment protection of industrial as well.
LP-24 series with multi-industry extension,USB,telecommunications,signal,fiber optic,HDMI,etc,and customized specialty ,pin series,such as :3pin,power+9pin,signal...


Connecting mode:	plug/unplug
Protection level:	IP65/IP68
Cable specification:	0.15mm2 ~ 0.20 mm2 /26~24AWG
Diameter range:	Φ5.5mm ~Φ7mm
Contact diameter×Qty:	8
Contact resistance:	<1mΩ
Insulation resistance:	>500MΩ
Durability:	≥500 mating&unmating cycles
Temperature rating:	-40°C~80°C
Method of connecting cable:	solder
Prevent the combustion level:	UL94-V0
Produce type:	Good Quality Rj45 Connector
Material:
Shell&insulated parts:	High performance engineering plastics
Hardware metal:	Zinc alloy(pearl hard chromium)
Contact pin:	Copper alloy(gold-plated)
Spring:	Stainless steel
Sealing:	Silica gel

Main characteristics:
- Sealed against dust and fluid (IP65/IP68)
- Vibration resistance,impact resistance,stretching resistance
- With one hand, can quickly insert or pull out

Application industries:
- Stage equipment	- The smart grid
- Medical equipment	- Server
- Solar energy equipment	- Ship equipment
- Electric power equipment	- Vehicle equipment
- Communications equipment	- Heavy machinery

Packaging & Shipping
1. 5pcs to a box, 40 boxes to a carton,or use customized packing with MOQ1000 pcs/model boxes.
2. Lead time: 7-10 working days after received deposit for USB Convert Serial Cable Connector
3. DHL/UPS/Fedex/EMS/TNT(door to door) or use customer partne

Our Services
1. Supply OEM and ODM service for USB Convert Serial Cable Connector
2. With professional quality control system and R&D department
3. To make customized needs with national level laboratory
4.Free samples are available for USB Convert Serial Cable Connector
5. supply the best service to you with the contact details below:
TEL:0086-0755-36853901 FAX:0086-0755-86960305
Cellphone: 0086-18312490297

Prod Model:	YT-RJ45-CPE-10-001, YT-RJ45-JSX-18-001
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Brand Name:	Cnlinko
Waterproof Rating:	IP65
Connecting Mode:	Push and Pull
Pin:	8pin
Shell & Insulated Parts:	High Performance Engineer Plastic
Current Rating(a):	1.5A
Operating Voltage:	500V
Colour:	Black
Temperature Rating:	-40°c~80°c
Type:	Single Hole Terminals
Material:	Copper
Application:	Transmission of Electrical Signals
Brand:	Cnlinko

Founded in 2004, Shenzhen Linko Electric Co., Ltd is a manufacturer in designing and manufacturing and marketing in the field of connectors.

We adhere to such principles"Integrity-base, quality-first, technological precedence&greater perfection. " After 10 years stabled developed, perfect management system was established, with creative, efficient, dedicated, rigorous R&D team, advanced production line.

Powerful product testing and quality testing laboratory and also covers dozens of professional files testing, excellent sales team and strong channels distribution net work.

Specializing in design high-performance industry connectors and approved by identification UL(E365869), CE, CCC, ISO9001-2008 and also with more than dozens of patents and international certifications.

We will always keep skills fresh and up-to data with international.

Cnlinko's products are widely used in variety of challenging enviroments, such as LED screen, LED lighting, Audio visual equipment, stage lighting, industrial automation equipment, heavy industrial equipment and the others.

Welcome to visit us and joint designing and develop new products, For the goal win-win cooperation and mutual benefit.
