UL Approved Wired Surface Mounted Magnetic Door Contact Switches

Name: UL Approved Wired Surface Mounted Magnetic Door Contact Switches
Brand: all-electronics-online.com
SKU: 699770482
Availability: InStock
Rating: 4.3 (113 reviews)

Price:	US $ 0.97/Piece
Trade Terms:	FOB
Min Order:	1000/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BS-2022
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Approved:	CE/UL
Color:	White/Brown/Grey

Product Description

UL Approved Wired Surface Mounted Magnetic Door Contact Switches

Specification:
.Screw mount or self adhesive
.Center leads with #22AWG 18" length

.Special leads on request
.Spacer,Cover or Tape available on request

.Switch or magnet available separately

.Resistor,Diode and Supervisory Loop available on request
.Colors: White, Brown, Grey

Order Information:

Part Number	Loop Type	Reed Form	Closed Gap [Inch (mm) ]	Depature Gap [Inch (mm) ]	Maximum Initial Contact Resistance (Ohm)	Maximum Contact Rating (W)	Maximum Switching Voltage (VDC/VAC)	Maximum Switching Current (A)
BS-2022	Closed	N/O	1.18(30)	1.3(33)	0.150	10	100	0.5
BS-2022WG	Closed	N/O	1.45(37)	1.53(39)	0.150	10	100	0.5
BS-2022A	Open	N/C	1^1/8(28)		0.150	3	30	0.2
BS-2022C	Closed & Open	SPDT	1^1/8(28)		0.150	3	30	0.2

UL APPROVED: BS-2022
Sentek is a company specializing in designing, developing and manufacturing fire & security detection products, such as smoke detectors, heat detectors, flame detectors, combustible and toxic gas detectors, magnetic door contact switches, PIR mostion sensors and so on.
We are growing day by day by improving quality, introducing new technology, developing new products since establishment in 2001. Adhering to the principal of "Technology Innovation, Precision Manufacturing", all our products are designed and manufactured strictly in accordance with the standards of EN, UL, KFI, VDS, FCC,etc. Meanwhile, with implementation of ISO9001 and PDM & ERP system, we Sentek are in the position to provide much better service to our clients.
Warmly welcome customers from all over the world to visit our factory, Sentek wish to build a safe and harmonious society together with you.
Fire & Security Detection:
- Smoke Detector/Alarm
- Heat Detector
- Gas Alarm
- CO Alarm
- Reed Sensor
- Door window Sensor
- PIR Motion Sensor
- Fire Alarm Control Panel
- Smart Home GatewayWarmly

Ningbo Sentek Electronics Co., Ltd., is a professional manufacturer in fire and security products, such as smoke detector, gas detector, magnetic contacts and so on.

Most of magnetic contacts are UL list, UL, EN approval for smoke detector and heat detector.

We are still like to be your OEM/ODM manufacturer in fire and security products, including reed sensors.

Warmly welcome customers for all over the world to talk and do business with us.
