10g Customized 10km 1310 LC XFP Optical Module Transceiver
| Price: |
US $ 0.1-200/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
xfp transceiver |
| Item Name: |
10g 10km XFP Transceiver |
| Working Rate: |
10g |
| Reach Distance: |
10-20km |
| Wavelength: |
1310 Nm |
| Adapter Type: |
LC |
| Keywords: |
XFP,XFP Transceiver,XFP Module |
| OEM: |
Available |
| Usage: |
Laptop |
| Type: |
Wired |
| Support Network: |
GSM |
| Information Content: |
Data |
| Certification: |
GS |
| Condition: |
New |
Product Description
10g Customized 10km 1310 LC XFP optical module TransceiverXFP Optical module Transceivers are hot-swappable, compact media connectors that provide instant fiber connectivity for your networking gear. They are a cost effective way to connect a single network device to a wide variety of fiber cable distances and types.
Applications- SDH STM I-64.1 at 9.953Gbps
- 10GBASE-LR/LW 10G Ethernet
- 1200-SM-LL-L 10G Fibre Channel
- 10GE over G.709 at 11.09Gbps
- OC192 over FEC at 10.709Gbps
- Other optical links, up to 11.1Gbps
Description
Takfly DF-R192-LRC is compliant with the 10G Small Form-Factor Pluggable (XFP)
Multi-Source Agreement (MSA), supporting data-rate of 10.3125Gbps(10GBASE-LR) or 9.953Gbps
10GBASE-LW), and transmission distance up to 10km on SMF.
The receiver module only use a PIN photodiode. Work temperature range of 0ºC to +70ºC and offers
optimum heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10 GbE systems.
Features- Supports 9.95Gb/s to 11.1Gb/s bit rates
- Hot-pluggable XFP footprint
- Maximum link length of 10km with SMF
- PIN ROSA
- XFP MSA package with duplex LC connector
- No reference clock required
- Compatible with RoHS
- +3.3V power supply
- Power dissipation <0.7W
- Built-in digital diagnostic functions
- Temperature range 0°C to 70°C
Ordering information| Part Number | Product Description |
| DF-R192-LRC | pin, 10Gbps, 10km, 0ºC ~ +70ºC. |
Why choose Takfly?1.High efficiency,with more than 3000 square meters size & 150+ professional workers can finish your order within a week
2.Quality assurance,we are a factory strictly operating ISO 9001:2008 quality control system,twice check before delivery
3.Competitve price.As a factory,costs are controllable
4.Flexible payment term.T/T,L/C,paypal is availble
5.Professional,Our workers are at least 3 years experience in fiber optic fields,besides,we cooperated with Electroson,Telefonica,etc
6.Complete product range, products cover fiber optic cable,Fiber optic adapter,attenuators,full total FTTH solution.
Takfly Communications Co., Ltd. is a Hi-Tech enterprise having its own brand and specializing in R&D, manufacture and sales of fiber optical communications equipments.
The main products of TAKFLY include fiber optic patch cord, connector, adapter, optical coupler, attenuator, optic media converter, optic splice closure, optic terminal box, ODF etc, which are widely used in telecommunications, broadband, broadcast, CATV and network industry. All the products acquired the approval of the Network Access License for Telecommunication Equipment Ministry of Information Industry, PRC, ISO9001, UL and CE standard, which ensure the reliability and make them sold very well not only in the domestic market but also the overseas market.
TAKFLY was establish in 2000, grow up rapidly. Now it has workshop area about 3000 square meters, more than 200 workers, the production capacity of fiber optic connectors is about 600, 000PCS per month. It controls the quality constantly and strictly in order to give the best products to the users. The outstanding features and advantage are the high technology, professional and excellent sales team, efficient and sound management, competitive price, wide and superior channels, as well as high-quality and flexible service.
Many international exhibitions upgraded "TAKFLY" as the well-known brand in the world. To be the super leader of the optical communications scopes in China is the goal of TAKFLY. In the next five years, TAKFLY will keep the strategic pattern of development ---"based in South China, penetrate into whole country, extend over the world". It will bring the fiber optic industry into a brilliant future. TAKFLY--- Your Honest Team, will be always ready for you.
