| Prod Model: |
WB-AI9104 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
DC9V 1000mA |
| Housing: |
Metal |
| Port: |
4 VGA Port |
| Video Resolution: |
1600 X 900 |
| Usage: |
Laptop |
| Type: |
Wired |
| Support Network: |
Ethernet |
| Information Content: |
Data |
| Certification: |
CE |
| Condition: |
New |
Product Description
Descriptions
Supports USB/PS/2 with OSD menu, which controls 4 PC/4 servers
One full set of monitor, keyboard, mouse-rack mountable, PC connection ports supports PS/2 and USB
Console port: supports USB and PS/2
Features:
One console controls 4 computers / servers
Be compatible with USB/PS2 keyboard, mouse in console and PS2, USB keyboard and mouse in computer
Computer selection via front panel switches and OSD
LEDs display for easy status monitoring
Auto scan mode for monitoring all computers
Superior video quality
Easy to install, no software required
Hot pluggable, add or remove computers for maintenance without powering down switch
Supports Microsoft Windows and Solaris
IP function: to realize remote controlled by IP card
| Type | WB-AI9104DU |
| Computer connections | 4 |
| CPU port selection | Front panel switches/OSD menu |
| Console connectors | Keyboard | 1 x PS/2 female (purple), 1 x USB Female |
| Mouse | 1 x PS/2 female (green), 1 x USB Female |
| Video | 1 x HD-15 female (blue) |
| CPU connectors | Keyboard | 1 x PS/2 female (purple), 1 x USB female |
| Mouse | 1 x PS/2 female (green), 1 x USB female |
| Video | 4 x HDB-15 male (blue) |
| LED's | On Line | 4 |
| Selected | 4 |
| IP Port | Net Connection | 1 x RJ45 Port |
| Reset | 1 x LED's |
| Default | 1 x LED's |
| Video resolution | 2048 x 1536(max) |
| Power | DC9V 1000mA |
| Operating temperature | -10˚C~50˚C |
| Storage temperature | -20˚C~60˚C |
| Housing | Metal |
| Weight | 2.94 Kg |
| Dimensions(L x W x H ) | 432 x 155 x 44 mm |
SAMPLE order: Shipped by International Express such as above
| Shipment | Note |
| Express | Door to door, very convenient, don't need to clearance or pick-up |
| By air | Airport to airport, you need to do the customs clearance and pick up the goods at your local airport |
| By sea | Port to port and you need to do the customs clearance and pick-up the goods at your local port |
Sample Service: We will collect some sample fees, will refund after you place order.
Package design support: We have brand team for your customized design.
Company Information
WEBITELECOMMS was built in 2003 and was awarded the rights of import and export in 2010.
Products range: 19" racks and cabinets, outdoor cabinets, structured cabling, fiber optic , PDU, KVM and Fiber media converter
Audit Report: CE,ROHS,ISO,SGS.
Showroom: About 100 square meters showroom.
Welcome to WEBITELECOMMS, believe that our professional team and service will help you stay step ahead in the market.
FAQ
1) What is your Payment term?
---T/T, L/C, Western Union could be accepted.
2) What is your Trade term?
---EXW, FOB, CNF, CIF is also ok.
3) What is the Loading Port?
--- Ningbo or Shanghai port.
4) What is your MOQ?
---MOQ of most our products is 5pcs, different items will be different. We have indicated the MOQ for each item in the price list.
5) What is your Product Warranty?
---As Europe market, we have CE RoHS and other international safety standard for our products.
---As other market, international safety standard certificate is also be provided.
Order info.| Model NO. | Description |
| WB-KS-3104 | Rack mountable KVM switch, 4 Cat5e port |
| WB-KS-3108 | Rack mountable KVM switch, 8 Cat5e port |
| WB-KS-3116 | Rack mountable KVM switch, 16 Cat5e port |
| WB-KI-3104 | Rack mountable KVM switch, 4 Cat5e port with remote control |
| WB-KI-3108 | Rack mountable KVM switch, 8 Cat5e port with remote control |
| WB-KI-3116 | Rack mountable KVM switch, 16 Cat5e port with remote control |
| WB-AS-3104 | Rack mountable KVM switch, 4 VGA port |
| WB-AS-3108 | Rack mountable KVM switch, 8 VGA port |
| WB-AS-3116 | Rack mountable KVM switch, 16 VGA port |
| WB-AI-3104 | Rack mountable KVM switch, 4 VGA port with remote control |
| WB-AI-3108 | Rack mountable KVM switch, 8 VGA port with remote control |
| WB-AI-3116 | Rack mountable KVM switch, 16 VGA port with remote control |
