Bore 12mm Mk Rotary Clamp Cylinder Standard

Name: Bore 12mm Mk Rotary Clamp Cylinder Standard
Brand: all-electronics-online.com
SKU: 821141825
Availability: InStock
Rating: 4.8 (116 reviews)

Price:	US $ 9.99-29.99/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	MK
Bore Size:	12t16t20t25t32t40t50t63
Rotary Stroke (mm):	7.5t9.5t15t19
Proof Pressure:	1.5MPa
Material:	Aluminum
Structure:	General Cylinder
Power:	Pneumatic
Standard:	Standard
Pressure Direction:	Double-acting Cylinder

Product Description

Features:

Bore sizes (mm): 12, 16, 20, 25, 32, 40, 50, 63
Standard stroke (mm): 10, 20, 30, 50 (depending on bore size)
Clockwise or counterclockwise rotary direction
Auto switch capable
The overall length is the same as the conventional styles, and mounting dimensions are interchangeable with the MK series.
Auto switches can be mounted on any of the 4 surfaces with no projection of the switch.

	Bore Size(mm)	Auto Switch
	Bore Size(mm)	Common
Direct Mounting	Ø12,Ø16,Ø32~Ø63	M9N M9B M9P
Rail Mounting	Ø20~Ø63	A73 Mounting Ø20,Ø25 is BQ-1 Ø32~Ø63 is BQ-2

Bore Size	12	16	20	25	32	40	50	63
Action	Double acting
Rotary angle	90 O ±10 O
Rotary direction	Clockwise, Counterclockwise
Rotary stroke (mm)	7.5		9.5		15		19
Clamp Stroke (mm)	10,20,30				10,20,30,50
Theoretical clamp force(N)	40	75	100	185	300	525	825	1400
Fluid	Air
Proof pressure	1.5MPa
Operating pressure range	0.1 to 1 MPa							0.1 to 0.6MPa
Ambient and fluid temperature	Without auto switch:-10 to 70 o C (No freezing) With auto switch:-10 to 60 o C (No freezing)
Lubrication	Non-lube
Piping port size	M5X0.8				Rc1/8,NPT1/8,G1/8		Rc1/4,NPT1/4,G1/4
Mounting	Through-hole/Both ends tapped common, Head flange
Cushion	Rubber bumper
Stroke length tolerance	0.6, 0.4
Piston speed	50 to 200 mm/s
Non-rotating accuracy(clamp part)	±1.4 o	±1.2 o			±0.9 o		±0.7 o
