Gl Closed Low Voltage Fuse (NT)

Name: Gl Closed Low Voltage Fuse (NT)
Brand: all-electronics-online.com
SKU: 753840745
Availability: InStock
Rating: 4.3 (114 reviews)

Price:	US $ 0.871-17.01/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	NT
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Western Europe
Fuse Link Rated Current (a):	2~160
Fuse Base Rated Current (a):	160
Fuse Link Rated Voltage (V):	500, 600
Fuse Link Weight (Kg):	0.15-0.2
Fuse Base Weight (Kg):	0.2-0.32
Breaking Capacity:	High
Type:	Current Fuse
Usaga:	Low Voltage

Product Description

Specification

Type	Fuse Link				Fuse Base
Type	Rated Current (A)	Rated Voltage (V)	Rated Power Loss(W)	Weight (kg)	Type	Rated Current (A)	Weight (kg)
NT00C	2	500, 600	0.41	0.15	Sist 101	160	0.2
	4		0.62
	6		0.81
	10		1.08
	16		1.60
	20		1.81
	25		2.31
	32		3.07
	36		3.17
	40		4.05
	50		4.25
	63		4.70
	80		5.7
	100		7
NT00	4	500, 600	0.67	0.15	Sist 101	160	0.2
	6		0.89
	10		1.14
	16		1.65
	20		1.94
	25		2.50
	32		3.32
	36		3.56
	40		4.30
	50		4.5
	63		4.6
	80		6
	100		7.3
	125	500	7.6
	160	500	9.6
NT0	6	500, 600	1.03	0.2	Sist 160	160	0.32
	10		1.42
	16		2.45
	20		2.36
	25		2.7
	32		3.74
	35		4.3
	40		4.7
	50		5.5
	63		6.9
	80		7.6
	100		8.9
	125	500	10.1
	160	500	15.2

Why us?

1.We have extensive experience in low tension electric items and illumination products, because we have been dealing the line for more than 24 years.

2. The prices of our products are very reasonable because we have a good network of raw material supply, spare parts and goods. And our factory is efficient, covering an area of 13,000 m².

3. The quality of our products are reliable because we have a group of professional inspectors supervising the quality during the production and before shipment. Our products have obtained TUV, SEMKO, CE, CB, and ROHS certificates.

4. The packing of our products is attractive because we have particular designers in charge of packing material in a unique style.

5. The service from our company is favorable, because we have experienced salesmen to handle business for you specially.

We are one of the most reliable manufacturers and exporters of low tension electrical items and illumination products in China. We have successfully developed and dealt with numerous electrical products in high quality, such as Circuit Breaker, AC Contact, Panel Enclosure, Electrical Accessories for Panel Enclosure, Pushbutton, Switch, Fuse, Meter, Temperature Controller, Cable Tie, Wiring System products as well as illumination items.

· Qualifications and Technological Strength

We possess full line of high-tech production equipment and great strength of technology support besides advanced designing forces powered by the first class engineering teams with super industrial computer systems. Thus, Our products are novel in designs, excellent in workmanship and tope reliable in quality. A lot of our products have obtained "RoHS", "CB", "CE" and "IRAM", and other international quality approvals. The products now are being well sold in more than 82 countries and regions in the world.

· Contact Us Today

We have always pays special attention to protecting the benefits of clients' so that both the clients ans our company are able to gain the maximum benefits from the relations between us. We warmly look forward to establishing, reinforcing and expanding long term fruitful relationship with the reliable clients all over the world.

Let's get busy and pull together to create a better future.
