Grid Connected Inverter-2KW-4KW (BF)

Name: Grid Connected Inverter-2KW-4KW (BF)
Brand: all-electronics-online.com
SKU: 646973285
Availability: InStock
Rating: 4.7 (52 reviews)

Price:	Negotiable/Piece
Trade Terms:	CIF
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	BF
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Capacity:	Bf2kw
Input Voltage:	48/96V
Working Design:	Low Voltage Design
Packing Size:	550300590mm
Delivery Time:	3-5 Days
Sytem:	Solar System or Wind Turbine System Used.
Warranty:	2 Years
Service:	Ship The Free Parts
Perfect Design:	Working on Grid System and off Grid System
OEM:	Accept

Product Description

Our grid connected inverter competitive advantage:
1)Working solar system and wind turbine systm;
2)Can get the power to the grid(on grid ), also can take th load directly(off grid )
3)Used copper transfromer;
4)LCD display all info
5)2 years warranty;
6)Ship the free parts for service

1)Digital DSP Control, Isolating by transformer. LCD display protection: Input power, output power; Input voltage, output voltage, input current, output current; Frequency, temperature and so on.
2)Assembled by IPM of Mitsubishi made in Japan
3)Have perfect protect function, the highest dependability of the system.
4)MPPT control, duly track of maximum power output of PV module
5)Pure sine wave output, auto in-phase grid-connected, fewer harmonic wave, no disturbance or impact on grid
6)Electromagnetic compatibility: EN50081, part1 EN50082, part1
7)Grid disturbance: EN61000-3-2
8)Grid text: DIN VDE 126

model	BF300		BF500		BF1		BF2K		BF3K		BF5K	BF10K		BF20K	BF50K
Rated Power(W)	300		500		1000		2000		3000		5000	10000		20000	50000
MPPTRange(VDC)	Vpv( 21-36VDC) or (46-75VDC)						Vpv (46-75VDC) or (82-128VDC)					Vpv(300-500V DC)
Maximum-Power-Of- Solar-Module-Array(KWp	0.36		0.6		1.2		2.2		3.4		5.5	12		24	56
Maximum Input Current Of Array	10-22A						20-100A					60-137.5A
Maximum-Open-Circuit-Voltage-Of Array	450VDC						450VDC					600VDC
Maximum Efficiency	94%											98%
MPPT Intensity	99%
Ripple Of DC Voltage	VPP< 10 %
Allowed Voltage Range Of Grid	90V-120V or 160-280VAC						90V-120V or 160-280VAC					380-415V AC
Allowed Frequency Range Of Grid	50HZ± 4.5/60HZ± 4.5
Wave Form	THD< 3 %
Loss At Night	< 0.5W
Power Coefficient	> 0.95											> 0.99
Maximum(kw)	0.33		0.55		1.1		2.2		3.3		5.4	12		24		56
Protective Functions	Protection Against Over load, Short-Circuit, Over Heat, Anti-isolated Island Effiency, Polarity Joint-Reversed
Insulated Strength	2500VAC, 1 Minute
Environment Temperature	-25 to +55
Environment Humidity	0-95%, Non Condensable
Protective Class	IP20 or IP 65(optional)
Machine(mm)	44095350					500450207				473230490				8006002060
Packingsize(mm)	540190440					550300590				590350540				8206352100
N. W(KG)	10	13.4		19		35.5		43.5		59			85	386			675
G. W(KG)	13	15.6		21		38		46		68			112	415			700
