Hr17 Knife Blade Fuse Disconnector

Prod Model:	HR17
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Western Europe
Rated Working Current Ie:	160, 250, 400, 630A
Rated Short Circuit Connecting Capacity:	1600, 2500, 4000, 6300A
Rated Limit Short Circuit Current Inc:	50ka
Rated Insulated Voltage Ui:	690V
Use Type:	AC-23b
Number Of Poles:	3, 4
Matched Fuse Link:	Nt00, Nt1, Nt2, Nt3
Breaking Capacity:	High
Type:	Current Fuse
Usaga:	High Voltage

Product Description

Specification


Model	Rated Working Current le	Rated Short  Circuit Connecting Capacity Icm	Rated Limit  Short Circuit  Current Inc	Rated Insulated Voltage Ui	Use Type	Number  of  Poles	Matched  Fuse Link
HR17-160	160A	1600A	50kA	690V	AC-23B	3, 4	NT00
HR17-250	250A	2500A					NT1
HR17-400	400A	4000A					NT2
HR17-630	630A	6300A					NT3

Dimension

Model	Assorted Fuse	A	B	C	D	a	b	Φc
HR17-160/30	NT100	106	200	83	205	66	25	Φ7
HR17-250/30	NT1	185	247	110	295	114	50	Φ11
HR17-400/30	NT2	210	290	125	340	130	50	Φ11
HR17-630/30	NT3	256	300	145	360	162	50	Φ11
HR17-160/40	NT100	138	200	83	205	100	25	Φ7
HR17-250/40	NT1	242	247	110	295	172	50	Φ11
HR17-400/40	NT2	276	290	125	340	195	50	Φ11
HR17-630/40	NT3	340	300	145	360	243	50	Φ11

Why us(fuse disconnector)?
1. We have extensive experience in low tension electric items and illumination products. We have been  dealing the line for more than 21 years.

2. The prices of our products are very reasonable because our network of raw material supply, spare parts and goods. And our factory is efficient, covering an area of 13,000 m².

4. Our  group of professional inspectors supervising the quality for your every order. Our products have  obtained TUV, SEMKO, CE, CB, and ROHS certificates.

5. We have particular designers in charge of packing.

6. We have experienced salesmen to handle business for you specially.

About us energy meter
nearly 20 years for Crimping Tool
1.  More than 23 years' experience. We have extensive experience in low tension electric items illuminaiton products.

2. Reasonable price. Good network of raw material supply, spare parts and goods and efficient factory covering an area of 13,000 m².

3. Reliable quality. We have professional inspectors supervising the quality during the production. Our products have obtained TUV, SEMKO, CE, CB and RoHS certificates.

4. Favorable service. We have experienced salesmen to handle business for you specially.

5. Attractive packing. We have particular designers in charge of packing material in a unique style.

OUR PRODUCING LINE (fuse disconnector)
