Invertors Solar Inverter Hybrid Controller, 2kw 3kw 12V 24V 48V Input for 220V 50Hz

Name: Invertors Solar Inverter Hybrid Controller, 2kw 3kw 12V 24V 48V Input for 220V 50Hz
Brand: all-electronics-online.com
SKU: 774391015
Availability: InStock
Rating: 4.7 (103 reviews)

Price:	US $ 2405/Piece
Trade Terms:	FOB,CIF,DAT
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	SC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Input Voltage:	12V 24V 48V 96V, 120V
Materials:	Full Copper Transformer
Colour:	According Customers Request
System:	Home System, Solar System, Wind System
Warranty:	2 Years
Delivery:	3-5 Days
After Sales Service:	Offer Free PCB Parts
Phase:	Single
Power Source:	Electric Power

Product Description

Invertors Solar Inverter Hybrid Controller, 2kw 3kw 12V 24V 48V Input For 220V 50Hz

Feature:
1.Combine with solar power controller and inverter hybrid function.
2.Completely controlled by CPU.
3.Inverter use copper transformer, pure sine wave output.
4..LCD displays, clearly to know the status.
5.have bypass function and AC charger (UPS function)
6.Perfect protection. Protect against anti-charge at night, battery over charger/over discharge, output short-circuit, against overload, against over-voltage, over-current protection ,etc.
7.Easy operation,only need connect the panels and batteries directly to the Hybrid solar inverter.

Our invertors competitive advantage:
1)Used copper transfromer;
2)LCD display
3)Bypass function and with AC charger;
4)18 months warranty;
5)Ship the free parts for service.
6)CE certification
We promise our best quality and after sales service. Make TANFON as your most valuable cooperator in China.

Foshan tanfon inverter used copper transformer, LCD display. LCD can display input voltage, output voltage, battery power percent. And so on.

The input voltage can produce customers request, from 96V, 120V, 196V, 220V, 240V, 360V.
Output voltage range is 160V-280V

Finding agent for this product. (all over the world)

MODEL		T1K	T3K	T5K	T10K	T15K	T20K		T30K	T60K	T100K
Power		1KW	3KW	5KW	10KW	15KW	20KW		30KW	60KW	100KW
Power Factor		0.8
Input	Phase	3 phase 4 wire and ground
	Voltage Range	380V± 20%(3 phase), phase voltage 220V
	Frequency Range	45 - 65Hz
	Rectifier	3 phase 6 pulses, 12 pulses is optional
Output	Phase	3 phase 4 wire and ground
	Wave form	Pure sine wave
	Crest Factor	3: 01
	Rated voltage	380/400/415V optional + -1% for static load, 5% for fluctuant load
	Phase voltage setting	200 - 244VAC, pls confirm when order
	Transient response	+/-5%, 10ms
	Frequency	50 / 60 Hz + / - 0.05%
	Total-harmonic distortion	< 3% linear load, < 5%( nonlinear load)
	Short circuit current	Short current for 0.1s (200% current)
	Overload capacity	Overload 125% for 10 Ms, 125%-150% for 1min. automatically resume when load become normal
Battery	Battery	Maintenance free lead-acid cell
	DC Voltage	48v or 96V(1-15KW)						384V
	Max Charge Current	6-30A adjustable
Bypass	Type	Static state + manual maintenance bypass
	Input Phase	3 phase 4 wire and ground
	Input voltage range	15% - 25% (the front control panel selectable)
	Transfer time	Inverter / bypass transfer switch time(Overload): 0ms inverter / bypass transfer switch time (fault inverter) 1ms
Efficiency	Whole unit	> 85%
	Inverter	91	91	92	92	93	93		95	95	95
Remote signaling		Dry contact (battery low, battery discharging, bypass/ fault); output 12Vdc/80mA, Optional parts
Communication interface		RS232 ( SNMP, modem optional )
Running temperature		0-40 degree Celsius
Relative Humidity		Less than 95% (without condensing)
Noise at 1 M		less than 60 dB
Degree of protection		IP20
Applicable Standards		EN50091-1-EMC EN50091-2liv. A
Product size(mm)		560230570		590470730		9006001380			12009001820
product weight(Kg)		30	40	54	104	125	190		380	690	800
Package size(mm)		640300730		690570850		11358101430			145011101880
Package weight(Kg)		32	50	60	123	145	215		420	750	860
